Запчасти Case IH STEIGER 335 (01A-11) - HYDRAULICS - CHARGE PUMP AND BRAKE CIRCUIT WITH ACCUSTEER (00) - PICTORIAL INDEX

1

PUMP, Gear, See Figure 08-26

1шт.

2

TUBE, Gear Pump Supply, High Output Hydraulics, See Figure 08-22

1шт.

3

HOSE, Gear Pump to Charge Pressure Tube, High Output Hydraulics, See Figure 08-22

1шт.

4

TUBE, Charge Pressure, To Filter, See Figure 08-09

1шт.

5

FILTER, Main Hydraulic (Below Battery), See Figure 08-04

1шт.

6

HOSE, Service Brake Line, to Front Axle, See Figure 07-04

1шт.

7

HOSE, Tow Valve Supply, To Rear Axle Park Brake, See Figure 07-06 & 07-08

1шт.

8

HOSE, Tow Valve Supply, To Front Axle Park Brake, See Figure 07-06 & 07-08

1шт.

9

VALVE, Regulator, See Figure 08-11

1шт.

10

HOSE, Regulator Output to Brake Valve, See Figure 07-06 & 08

1шт.

11

VALVE, Brake, See Figure 07-02

1шт.

12

HOSE, Brake Valve, Return To Tank, See Figure 07-06 & 07-08

1шт.

13

HOSE, Service Brake, To Rear Axle, See Figure 07-04

1шт.

14

HOSE, Service Brake, To Front Axle, See Figure 07-04

1шт.

15

SOLENOID, Differential Lock, Used In Differential Lock Applications, See Figure 07-09

1шт.

16

TUBE, Differential Lock, Used In Differential Lock Applications, See Figure 07-08

1шт.

17

TUBE, Regulator Output to Brake Valve, See Figure 07-06 & 07-08

1шт.

18

TUBE, Brake Valve Return to Tank, See Figure 07-06 & 07-08

1шт.

19

TUBE, Service Brake Line, See Figure 07-04

1шт.

20

TUBE, Return to Tank, See Figure 08-06

1шт.

21

TANK, Hydraulic, See Figure 08-16

1шт.
