(01A-21) - HYDRAULICS - HYDRAULIC FAN DRIVE CIRCUITRY, STEIGER 485

Запчасти Case IH STEIGER 485 (01A-21) - HYDRAULICS - HYDRAULIC FAN DRIVE CIRCUITRY, STEIGER 485 (00) - PICTORIAL INDEX

Схема запчастей Case IH STEIGER 485 - (01A-21) - HYDRAULICS - HYDRAULIC FAN DRIVE CIRCUITRY, STEIGER 485 (00) - PICTORIAL INDEX
8
2
9
14
1
5
11
7
9
10
13
3
6
08-19
02-07
08-49
08-47
08-47
08-28
08-47
08-47
08-47
08-47
08-47
08-47
08-47
08-47
08-47
08-20
4
12
8
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

Cooler, Hydraulic Oil, See Figure 08-47

1шт.

2

Motor, Hydraulic Fan, See Figure 02-07

1шт.

3

Hose, Fan Motor Supply, See Figure 08-47

1шт.

4

Tube, Fan Motor Supply, See Figure 08-47

1шт.

5

Hose, Case Drain, See Figure 08-44

1шт.

6

Pump, High Output Hydraulic, See Figure 08-28

1шт.

7

Tube, Fan Motor Return To Tank, See Figure 08-47

1шт.

8

Hose, Fan Motor to Cooler, See Figure 08-47

1шт.

9

Hose, Cooler Return to Tank, See Figure 08-47

1шт.

10

Hose, Fan Motor Return to Pump, See Figure 08-47

1шт.

11

Hose, Pump Return to Tank, See Figure 08-47

1шт.

12

Hose, Case Drain, See Figure 08-47

1шт.

13

Pump, Hydraulic Fan Drive, See Figure 08-49

1шт.

14

Tank, Hydraulic, Wheel Tractor, See Figure 08-19

1шт.

14

Tank, Hydraulic, QUADTRAC Tractor, See Figure 08-20

1шт.
