Запчасти Case 1850K (9.470[02]) - TILT CYLINDER - FRONT IMPLEMENT - OPTIONAL CODE 76090661 - 76090748 - 76090936 (19) - OPTIONS

1

76090663

BARREL

Assy

1шт.

2

8283381

BUSHING,70.21mm ID x 82mm OD x 45mm L

M16 x 30 x 3

1шт.

3

76090664

FLANGE

1шт.

4

79071307

SEAL

1шт.

5

16040034

BOLT,Hex, M18 x 90mm, Cl 10.9

6шт.

6

71415218

WASHER,19mm ID x 36mm OD x 4mm Thk

M36 x 19 x 4.5

6шт.

7

76090665

GLAND

1шт.

8

8298265

RING

M132.9 x 3.53

1шт.

9

14467080

O-RING,0.139" Thk x 5.234" ID, -252, Cl 5, 75 Duro

(M132.9 ID x 3.53 Thk)

1шт.

10

79056407

PISTON

1шт.

11

8292367

SEAL,115mm ID x 140mm OD x 25.4mm Thk

1шт.

12

8292259

NUT

1шт.

13

79074953

ROD

1шт.
