Запчасти Case 1280B (088) - BATTERY AND ALTERNATOR MOUNTING PARTS, USED WITH CASE ENGINE (04) - ELECTRICAL SYSTEMS

1

S515546

BRACKET

RETAINER - battery, mounting parts

2шт.

2

S75713

STUD

BOLT - battery holddown, mounting parts

4шт.

3

195-103

WASHER,5/16"

- flat, , battery mounting parts 5/16"

4шт.

4

231-1445

NUT,5/16"-18, GB

NUT - hex, self-locking, 5/16" - 18 NC, Battery mounting parts

4шт.

5

S117291

STRIP

- rubber, battery box, mounting parts

4шт.

6

S516619

BATTERY BOX

BOX - battery, mounting parts

1шт.

7

113-424

BOLT,Hex, 1/2" - 13 x 1", Gr 5, Full Thd

- hex head, 1/2" - 13 NC x 1-1/4", battery mounting parts

2шт.

8

192-23

LOCK WASHER,1/2"

WASHER, LOCK, , Battery mounting parts 1/2"

2шт.

9

S95569

WASHER

- flat, hardened, 1/2", battery mounting parts

2шт.

10

A160391

BRACKET

- alternator mounting, parts

1шт.

11

S242605

STRAP

- alternator adjusting (replaces S238535), mounting parts

1шт.

12

113-207

BOLT,Hex, 3/8" - 16 x 1", Gr 5

- hex head, 3/8" - 16 NC x 3/4", alternator mounting parts

3шт.

13

192-21

LOCK WASHER,3/8"

WASHER, LOCK, , Alternator mounting parts 3/8"

3шт.

14

195-525

WASHER,3/8", SAE

- flat, 3/8", alternator mounting parts

2шт.

15

113-247

BOLT,Hex, 3/8" - 16 x 3-1/4", Gr 5

- hex head, 1/2" - 13 NC x 3", alternator mounting parts

1шт.

16

131-52

NUT,3/8"-16, GC

NUT - hex, self-locking, 1/2" - 13 NC, alternator mounting parts

1шт.

17

113-103

BOLT,Hex, 5/16" - 18 x 1", Gr 5

Alternator mounting parts Hex, 5/16"-18 x 1", G5, Full Thd

1шт.

18

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

WASHER, LOCK, , Alternator mounting parts 5/16"

1шт.

19

195-521

WASHER,5/16", SAE

- flat, 5/16", alternator mounting parts

1шт.
