Запчасти Case CX210D LC LR (35.359.AY[03]) - VAR - 461863, 461557 - RELIEF VALVE, CLAMSHELL BUCKET, ROTATION, COMPONENTS (35) - HYDRAULIC SYSTEMS

1

KRJ37530

CONTROL VALVE

ASSY, Incl 2 - 15

1шт.

See also figure 35.359.AB (05), 35.359.AB (06), 35.359.AB (07), 35.359.AB (08)

1шт.

2

155223A1

O-RING

4шт.

3

LJ00734

HYDRAULIC VALVE

ASSY, Incl 2 (Qty 1), 4 (Qty 1), 6 (Qty 1), 7 - 9

2шт.

4

154463A1

O-RING

4шт.

5

LJ014740

VALVE PRESSURE RELIE

ASSY, Incl 2 (Qty 1), 4 (Qty 1)

1шт.

6

164905A1

BACK-UP RING

4шт.

7

164906A1

O-RING

1шт.

8

163323A1

O-RING

1шт.

9

164575A1

BACK-UP RING

2шт.

10

LJ022730

VALVE

, Serial Range: -NFE7H1003

2шт.

10

LJ023210

VALVE

, Start Serial: NFE7H1004

2шт.

11

LJ014780

CHECK VALVE

ASSY, Incl 2 (Qty 1)

1шт.

12

LJ01196

VALVE, PRESSURE RELI

2шт.

13

LJ014750

CHECK VALVE

ASSY, Incl 4 (Qty 1), 6 (Qty 1)

2шт.

14

LJ01195

VALVE, PRESSURE RELI

1шт.

15

LJ023170

VALVE

1шт.
