(35.359.AB[05]) - VAR - 461863 - CONTROL VALVE, MOUNTING, BRACKET, CLAMSHELL BUCKET, ROTATION, W/ ELECTRICAL PROPORTIONAL CONTROL

Запчасти Case CX250D LC LR (35.359.AB[05]) - VAR - 461863 - CONTROL VALVE, MOUNTING, BRACKET, CLAMSHELL BUCKET, ROTATION, W/ ELECTRICAL PROPORTIONAL CONTROL (35) - HYDRAULIC SYSTEMS

Схема запчастей Case CX250D LC LR - (35.359.AB[05]) - VAR - 461863 - CONTROL VALVE, MOUNTING, BRACKET, CLAMSHELL BUCKET, ROTATION, W/ ELECTRICAL PROPORTIONAL CONTROL (35) - HYDRAULIC SYSTEMS
1
2
8
4
6
8
3
35.359.ab (06)
5
7
39.101.ac
3
3
4
6
5
7
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

KBJ24430

CONTROL VALVE

ASSY

1шт.

See also Figure 35.359.AB (06), 35.359.AB (07), 35.359.AB (08), 35.359.AY (02)

1шт.

2

KBJ19410

BRACKET

1шт.

3

166373A1

BOLT,Sems, M16 x 40mm

8шт.

4

KBJ19550

BRACKET

2шт.

5

862-12030

HEX SOC SCREW,M12 x 30mm, Cl 12.9

2шт.

6

NSS

NOT SOLD SEPARAT

Fitting, Incl in 8

2шт.

7

154475A1

O-RING

2шт.

8

KHJ18190

STUD

ASSY, G3/8" x M18, Incl 6 (Qty 1), 7 (Qty 1)

2шт.
