(55.014.AC) - STD + VAR - 488031 - AIR CLEANER, VACUUM GAUGE

Запчасти Case CX300D LC (55.014.AC) - STD + VAR - 488031 - AIR CLEANER, VACUUM GAUGE (55) - ELECTRICAL SYSTEMS

Схема запчастей Case CX300D LC - (55.014.AC) - STD + VAR - 488031 - AIR CLEANER, VACUUM GAUGE (55) - ELECTRICAL SYSTEMS
1
2
3
10.202.ab (01)
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

KHH17440

SENSOR

, Serial Range: -C0256

1шт.

Parts is included in Air Cleaner Assembly PN KBH14820, KBH14821, KBH14830, KBH14831

1шт.

1

KHH17441

SENSOR

, Start Serial: D0256

1шт.

Parts is included in Air Cleaner Assembly PN KBH14820, KBH14821, KBH14830, KBH14831

1шт.

2

KHR42760

TUBE

1шт.

3

150496A1

MOUNTING CLIP

250mm

2шт.
