(98A00020801[001]) - DECALS (NORTH AMERICAN ONLY) (8998340696)

Запчасти Case 335B (98A00020801[001]) - DECALS (NORTH AMERICAN ONLY) (8998340696) (19) - OPTIONS

Схема запчастей Case 335B - (98A00020801[001]) - DECALS (NORTH AMERICAN ONLY) (8998340696) (19) - OPTIONS
17
4
11
6
3
12
19
14
13
7
9
8
12
5
16
2
15
4
3
1
4
18
10
9
14
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

8998340696

DECAL KIT

Inc. 2-19

1шт.

2

8998196467

DECAL

Warning Use Seat Belt

1шт.

3

8998196469

DECAL

Warning Hot Surfaces

8шт.

4

8998196471

DECAL

Warning Visibility

3шт.

5

8998196475

DECAL

Warning Hot Liquid

1шт.

6

8998196477

DECAL

Warning Slip Hazzard

2шт.

7

8998196479

DECAL

Warning Keep Clear

4шт.

8

89500404121

DECAL

Warning Crush Hazzad

1шт.

9

8998196583

DECAL

Warning Keep Clear

2шт.

10

8998196585

DECAL

Warning crush Hazzard

1шт.

11

89500404122

DECAL

Warning Disconnect

1шт.

12

8998196593

DECAL

Warning Crush Hazzard

2шт.

13

89500404127

DECAL

Warning Read Manual

1шт.

14

89500409425

DECAL

Warning Pressurized System

4шт.

15

89500409437

DECAL

Warning Engine Start

1шт.

16

89500410027

DECAL

Warning Hood Release

1шт.

17

89500411174

DECAL

Caution Parking

1шт.

18

89500424562

DECAL

Warning Cab Tilt Pump

1шт.

19

89500424559

DECAL

Warning Hood Tilt Pump

1шт.
