(88.090.11[09]) - DIA KIT, CANOPY CONVERSION WIDE -DLX

Запчасти Case 590SN (88.090.11[09]) - DIA KIT, CANOPY CONVERSION WIDE -DLX (88) - ACCESSORIES

Схема запчастей Case 590SN - (88.090.11[09]) - DIA KIT, CANOPY CONVERSION WIDE -DLX (88) - ACCESSORIES
90.150.07
home
2
1
90.150.0701
3
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84410617

KIT

Canopy Conversion Wide - DLX, Incl 2 - 3, Serial Range: -`0

1шт.

See Ref. 88.090.11 [01] to 88.090.11 [08], 88.090.11 [10] to 88.090.11 [11]

1шт.

Refer to Installation Instructions for Correct Assembly Procedure

1шт.

2

280-16516

SELF-TAP SCREW,Hex Wash Hd, #10 x 1"

4шт.

3

390551A2

FLOOR MAT

1шт.
