(9.00580[02]) - ROPS CANOPY - COMPONENTS - OPTIONAL CODE 749260001 - VERSION (02)

Запчасти Case TX742 (9.00580[02]) - ROPS CANOPY - COMPONENTS - OPTIONAL CODE 749260001 - VERSION (02) (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case TX742 - (9.00580[02]) - ROPS CANOPY - COMPONENTS - OPTIONAL CODE 749260001 - VERSION (02) (90) - PLATFORM, CAB, BODYWORK AND DECALS
r
a
1
1.82.3
p
p
7
9.00448/a
a
l
8
pag.11
ls
t
1.82.3
2
1.82.0
ls
cf
3
9.00448
1.82.0
6
5
1.63.0
4
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

76091265

FLEXIBLE HOSE

1шт.

2

87388984

HOSE

1шт.

3

87388985

HOSE

1шт.

4

87388986

HOSE

1шт.

5

87388994

HOSE

1шт.

6

76076087

FITTING,M12 x 1.5 ORB x 9/16"-18 ORFS

1шт.

7

78100094

FITTING,M18 x 1.5

- Assy

4шт.

8

70923841

O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro

1шт.
