SEAT ASSY - MECHANICAL SUSPENSE

Запчасти Doosan Daewoo SEAT ASSY - MECHANICAL SUSPENSE BODY PARTS

1-6
1-21
1-7
1-3
1-2
1-22
1-1
1-4
1-5
1-15
1
1-16
1-17
1-20
1-13
1-14
1-11
1-8
1-23
2
1-18
3
3
1-12
2
1-19
1-10
1-15
1-9
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

-

K1006125A

SEAT ASS'Y-MECHANICAL SUSPENSE

SC: D

-2шт.

1

4901-9036

SEAT

desc: SIEGE

1шт.

1-1

2.161-00017

UPPER ASS'Y

desc: . SIEGE

1шт.

1-2

2.430-00274

BACK COVER

desc: . COUVERCLE

1шт.

1-3

2.161-00013

BACK FOAM

desc: . EPONGE

1шт.

1-4

1.430-00214

SEAT COVER

desc: . COUVERCLE

1шт.

1-5

1.161-00013

SEAT FOAM

desc: . EPONGE

1шт.

1-6

1.604-00001

FRAME

desc: . CHASSIS

1шт.

1-7

2.429-00040

HEAD REST

desc: . TETE DE VERIN

1шт.

1-8

2.131-00382

SPRING;HEIGHT RISER

desc: . RESSORT

1шт.

1-9

2.106-00005

TETHER BELT

desc: . COURROIE

1шт.

1-10

2.161-00011

DAMPER ASS'Y

desc: . DAMPER

1шт.

1-11

2.300-00002

SUSPENSION ASS'Y

desc: . SUSPENSION

1шт.

1-12

2.195-00020

FORE & AFT ADJUSTER

desc: . ADJUSTEUR

1шт.

1-13

2.151-00001

WEIGHT ADJUSTER

desc: . ADJUSTEUR

1шт.

1-14

2.416-00037

UPSTOP/BUMPSTOP

desc: . UPSTOP/BUMPSTOP

1шт.

1-15

2.172-00001

HANDLE

desc: . POIGNEE

1шт.

1-16

2.131-00383

HEIGHT RISER SPRING

desc: . RESSORT

1шт.

1-17

2.430-00385

SUSPENSION COVER

desc: . COUVERCLE DE SUSPENSION

1шт.

1-18

2.172-00012

SLIDE RAIL HANDLE

desc: . POIGNEE

1шт.

1-19

2.109-00088

BEARING KIT

desc: . PALIER

1шт.

1-20

1.901-00002

SEAT BELT

desc: . COURROIE

1шт.

1-21

2.197-00024

ARM REST-L.H

desc: . REPOSE-PIED

1шт.

1-22

2.197-00025

ARM REST-R.H

desc: . REPOSE-PIED

1шт.

1-23

2.125-00001

HEIGHT RISER LATCH

desc: . LOQUET

1шт.

2

S2209466

BOLT

desc: BOULON A 6 PANS

4шт.

3

K1006505A

BRACKET;CASE

desc: SUPPORT

2шт.
