Запчасти Doosan Daewoo TRAVEL MOTOR - ROTARY GROUP HYDRAULIC PARTS

-

2.407-00027

GROUP;ROTARY

desc: GROUPE ROTATOIRE

1шт.

1

2.409-00245

ROTARY

desc: DISTRIBUTEUR

1шт.

1A

2.424-00354

CYLINDER

desc: . CYLINDRE

1шт.

1B

2.412-00353

LENS;CONTROL

desc: . OBJECTIF

1шт.

1C

2.123-00285

PIN;CENTER

desc: . GOUPILLE

1шт.

1D

409-00039

PISTON & SHOE ASS'Y

desc: . ENSEMBLE DE PISTON CHAUSSURE

7шт.

1F

2.114-01342

SHIM;ADJUSTMENT

desc: . PLAQUE

1шт.

1G

2.129-00020

SPRING;PRESSURE

desc: . RESSORT

1шт.

1H

2.115-00537

PLATE;RETAINING

desc: . PLAQUE

1шт.

1I

2.120-00800

SCREW

desc: . VIS

14шт.

2

2.405-00238

SHAFT;DRIVE

desc: ARBRE MOTEUR

1шт.

3

2.114-01334

SHIM

desc: CALE

1шт.

6

2.180-01207

PLATE;BACK UP

desc: PLAQUE

1шт.

7

S6500750

RING;RETAINING

desc: RONDELLE DE RETENUE

1шт.

10

2.109-00334

BEARING;TAPER ROLLER

desc: ROULEMENT A ROULEAUX CONIQUES

1шт.

11

2.109-00245

BEARING;TAPER ROLLER

desc: ROULEMENT A ROULEAUX CONIQUES

1шт.
