Запчасти Doosan Daewoo TURBO CHARGER & OIL PIPE ENGINE PARTS
203
202
203
103
201
104
206
101
105
106
207
108
107
204
205
111
113
102
109
112
118
120
119
117
121
110
116
115
122
114
123
101
65.09100-7081
TURBO CHARGER ASS'Y
SERIAL: 020730
1шт.
101
65.09100-7081A
TURBO CHARGER ASS'Y
SERIAL: 020731
1шт.
102
65.09901-0018A
GASKET
desc: JOINT
1шт.
103
06.11024-9202
NUT M10X1.25
desc: ECROU
4шт.
104
06.16731-2108
WASHER;SPRING
desc: RONDELLE
4шт.
105
65.09901-0020
GASKET
desc: JOINT
1шт.
106
06.06225-0708
BOLT;STUD M8X30
SERIAL: 040916
4шт.
106
65.90201-0096
BOLT;STUD M8X30
SERIAL: 040917
4шт.
107
06.11063-8214
NUT;HEX. M8
desc: ECROU
4шт.
108
06.16731-2107
WASHER;SPRING
desc: RONDELLE
4шт.
109
65.98130-0200
ADAPTER
SERIAL: 020813
1шт.
109
65.98130-0200A
ADAPTER
SERIAL: 020814
1шт.
110
65.05701-5476
OIL PIPE ASS'Y
desc: CONDUITE
1шт.
111
06.78144-2403
SCREW;HOLLOW M12X1.5
desc: VIS CREUSE
1шт.
112
06.56190-0709
RING;SEAL
desc: BAGUE D'ETANCHEITE
1шт.
113
06.56190-0704
RING;SEAL
desc: BAGUE D'ETANCHEITE
2шт.
114
65.98155-0011
UNION;HOLLOW
desc: GRAISSEUR
1шт.
115
06.56180-0714
RING;SEAL
desc: BAGUE D'ETANCHEITE
2шт.
116
06.12172-9314
NUT;CAP
desc: ECROU
1шт.
117
65.97480-0135
HOLDER
desc: POSSESSEUR
1шт.
118
06.01913-3110
BOLT ASS'Y M8X12
desc: BOULON A 6 PANS
1шт.
119
65.05701-5477
OIL PIPE ASS'Y
desc: CONDUITE
1шт.
120
65.96601-0045A
GASKET
desc: JOINT
1шт.
121
06.01913-3115
BOLT ASS'Y M8X25
desc: BOULON A 6 PANS
2шт.
122
65.96301-0191
HOSE;RUBBER
desc: TUYAU FLEXIBLE
1шт.
123
06.67020-0106
CLAMP;HOSE
desc: COLLIER
2шт.
201
65.09411-5058
PIPE;INLET
desc: CONDUITES
1шт.
202
65.96301-0279
HOSE;RUBBER
desc: TUYAU FLEXIBLE
1шт.
203
06.67020-0109
CLAMP;HOSE
desc: COLLIER
2шт.
204
65.09440-0018
BRACKET
desc: SUPPORT
1шт.
205
06.01923-3215
BOLT ASS'Y M10X25
desc: BOULON A 6 PANS
2шт.
206
65.91701-0252
SPACER M18X25
desc: BAGUE D'ECARTEMENT
1шт.
207
65.91701-0187
SPACER M16X71
desc: BAGUE D'ECARTEMENT
1шт.
