Запчасти Doosan Daewoo OIL COOLER ENGINE PARTS
1
3
4
9
2
15
14
11
19
4
20
7
6
5
16
10
24
25
13
18
8
7
6
18
23
17
12
21
23
22
1
65.05601-7072C
OIL COOLER ASS'Y
desc: REFROIDISSEUR D'HUILE
1шт.
2
65.05604-0019B
HOUSING;OIL COOLER
desc: . COUVERCLE
1шт.
3
65.05606-5027B
ELEMENT;OIL COOLER
desc: . ELEMENTRE
1шт.
4
65.05903-0028
GASKET;OIL COOLER
desc: . RONDELLE DE BUTEE
2шт.
5
06.02090-0512
BOLT;SOCKET HEAD M10X25
desc: . BOULON A 6PANS
2шт.
6
06.02090-0513
BOLT;SOCKET HEAD M10X30
desc: . BOULON A 6PANS
2шт.
7
06.16731-2108
WASHER;SPRING
desc: . RONDELLE
4шт.
8
06.15010-2312
WASHER;PLAIN
desc: . RONDELLE
4шт.
9
65.01907-0008A
GASKET
desc: RONDELLE DE BUTEE
1шт.
10
06.01923-3124
BOLT ASS'Y M8X65
desc: BOULON A 6PANS
16шт.
11
65.90201-0066
BOLT;STUD
desc: BOULON DE PLOT
2шт.
12
06.01923-3122
BOLT ASS'Y M8X55
desc: BOULON A 6PANS
2шт.
13
06.01923-3115
BOLT ASS'Y M8X25
desc: BOULON A 6PANS
4шт.
14
06.16731-2107
WASHER;SPRING
desc: RONDELLE ELASTIQUE
2шт.
15
06.15010-2311
WASHER
desc: RONDELLE
2шт.
16
65.05701-5325
OIL PIPE ASS'Y(O/F-O/C)
desc: CONDUITE
1шт.
17
06.78140-2408
SCREW;HOLLOW
desc: VIS
1шт.
18
06.56190-0727
RING;SEAL
desc: BAGUE D'ETANCHEITE
2шт.
19
65.05903-0030A
GASKET;OIL RETURN PIPE
desc: JOINT
1шт.
20
06.01913-3120
BOLT ASS'Y M8X45
desc: BOULON A 6PANS
2шт.
21
65.05701-5964A
OIL PIPE ASS'Y
desc: TUYAU D'HUILE
1шт.
22
06.78140-2408
SCREW;HOLLOW
desc: VIS
1шт.
23
06.56190-0728
RING;SEAL
desc: BAGUE D'ETANCHEITE
2шт.
24
65.05903-0030A
GASKET;OIL RETURN PIPE
desc: JOINT
1шт.
25
06.01913-3120
BOLT ASS'Y M8X45
desc: BOULON A 6PANS
2шт.
