Запчасти Doosan Daewoo STEERING UNIT STEER PIPING

-

420-00418

STEERING UNIT

desc: UNITE

1шт.

1

633B9002

RING;DUST SEAL

SC: K

1шт.

2

-

HOUSING SPOOL & SLEEVE

SC: D

1шт.

3

689X1031

BALL Ґх8.5mm

desc: . BILLE

1шт.

4

150-0304

BUSHING;THREAD

desc: . BUSH

1шт.

5

150N4014

O-RING/ROTO GLYD

SC: K

1шт.

7

150-4262

BEARING ASS'Y

desc: . ROULEMENT

1шт.

8

150-0310

RING

desc: . ANNEAU

1шт.

9

150-0305

PIN;CROSS

desc: . GOUPILLE

1шт.

11

150-0844

CARDON SHAFT

desc: . TOURNEVIS EN CROIX

1шт.

12

150N4019

SET OF SPRINGS

desc: . RESSORT

1шт.

13

633B1202

O-RING

SC: K

3шт.

14

150N0610

DISTRIBUTOR PLATE

desc: . PLAQUE

1шт.

15

150-4174

GEARWHEEL SET

desc: . PIGNON

1шт.

17

150-0328

COVER;END

desc: . COUVERCLE

1шт.

18

684X2481

WASHER

SC: K

7шт.

20

150-1450

SCREW WITH PIN

desc: . VIS

1шт.

21

681X1579

SCREW

desc: . VIS

6шт.

*

150N4042

SEAL KIT

desc: JOINT

1шт.
