/ / / / / PLANETARY GEAR - FRONT AXLE
Запчасти Doosan Daewoo PLANETARY GEAR - FRONT AXLE HYDRAULIC PARTS
400
281
282
20
252
160
10
250
192
270
30
190
80
180
50
40
210
150
30
50
90
120
130
100
110
60
70
10
K9000624
HOUSING
SERIAL: 3001-3334
2шт.
10
K9000340
HOUSING
SERIAL: 3335
2шт.
20
K9000032
PLUG
desc: BOUCHON
2шт.
30
K9000179
O-RING
desc: JOINT TORIQUE
4шт.
40
K9000334
GEAR;RING
desc: PIGNON
2шт.
50
K9000176
O-RING
desc: JOINT TORIQUE
4шт.
60
K9000279
SEAL;SLIDE RING
SERIAL: 3001-3334
2шт.
60
K9000240
SEAL;SLIDE RING
SERIAL: 3335
2шт.
70
K9000324
BEARING;TAPPER ROLLER
desc: ROULEMENT
2шт.
80
K9000323
BEARING;TAPPER ROLLER
desc: ROULEMENT
2шт.
90
K9000625
SHAFT;OUTPUT
SERIAL: 3001-3334
2шт.
90
K9002863
SHAFT;OUTPUT
SERIAL: 3335
2шт.
100
K9000292
NUT;ADJUSTING
desc: ECROU
2шт.
110
K9000173
PIN;SLOT
desc: GOUPILLE
2шт.
120
K9000286
COVER
desc: COUVERCLE
2шт.
130
2.180-00284
O-RING
desc: JOINT TORIQUE
2шт.
150
K9000337
SHAFT;SUN GEAR
desc: ARBRE
2шт.
160
K9000336
GEAR;PLANET
desc: PIGNON
8шт.
180
K9000341
CARRIER;PLANET
desc: PORTEUR DE PLANETE
2шт.
190
K9000318
PLATE;OIL COLL
SERIAL: 3001-3334
8шт.
192
K9000305
SCREW;CAP
SERIAL: 3001-3334
16шт.
210
K9000277
BOLT;STOP
desc: BOULON
2шт.
250
K9000321
RING;BEARING INNER
desc: ANNEAU
8шт.
252
K9000322
RING;BEARING INNER
desc: ANNEAU
8шт.
270
K9000171
RING;RETAINING
desc: ANNEAU DE SOUTIEN
8шт.
281
K9000164
SCREW;PLUG
SERIAL: 3335
2шт.
282
1.180-00137
O-RING
SERIAL: 3335
2шт.
400
K9002864
BOLT;WHEEL
SERIAL: 3335
32шт.
