Запчасти Doosan Daewoo TRAVEL REDUCTION GEAR HYDRAULIC PARTS

-

401-00422

TRAVEL DEVICE

desc: ENSEMBLE MOTEUR

1шт.

-

2.401-00059

TRAVEL REDUCTION GEAR

SC: D

1шт.

C2

2.230-00001

CARRIER 2 SUB ASS'Y

desc: PORTEUR

1шт.

104

CARRIER 2

desc: . PORTEUR

1шт.

107

GEAR;B2

desc: . PIGNON

3шт.

108

GEAR;S1

desc: . PIGNON

1шт.

111

PIN;B2

desc: . GOUJON

3шт.

117

NEEDLE

desc: . GRAISSEUR

39шт.

121

WASHER;THRUST

desc: . RONDELLE

6шт.

123

RING;SNAP

desc: . BAGUE D'ETANCHEITE

1шт.

127

PIN;SPRING

desc: . GOUJON

3шт.

137

RING;SNAP

desc: .

3шт.

101

2.402-00025

BODY

desc: CARTER

1шт.

102

2.430-00172

COVER

desc: COUVERCLE

1шт.

106

2.404-00005

GEAR;B1

desc: PIGNON

4шт.

112

2.180-01042

RING;SEAL

desc: BAGUE

1шт.

113

2.115-00375

RING;SNAP

desc: BAGUE D'ARRET

1шт.

114

2.412-00286

PLATE;THRUST

desc: PLAQUE

1шт.

115

2.109-00164

RING;SIDE

desc: BAGUE

1шт.

116

2.115-00329

NEEDLE

desc: AIGUILLE

60шт.

118

2.427-00016

SEAT;FLOATING

desc: RESSORT

1шт.

120

2.109-00057

BEARING

desc: PALIER

2шт.

122

2.115-00544

RING;SNAP

desc: BAGUE D'ARRET

1шт.

131

2.181-00196

PLUG

desc: BOUCHON

2шт.

134

2.114-01147

WASHER;THRUST

desc: RONDELLE

4шт.

135

2181-1890D2

PLUG

desc: BOUCHON

2шт.

137

2.115-00374

RING;SNAP

desc: BAGUE D'ARRET

4шт.

138

2.115-00105

RING

desc: BAGUE

4шт.

C9-1

2.180-01234

SEAL KIT;T/REDUCTION GEAR

desc: KIT D'ETANCHEITE

1шт.

129

PPS-W-3X12

O-RING

desc: . JOINT TORIQUE

1шт.

130

FRP-1464-37

O-RING

desc: . JOINT TORIQUE

1шт.

136

GHC-1-2-1185

O-RING

desc: . JOINT TORIQUE

2шт.

139

O-RING

desc: . JOINT TORIQUE

2шт.
