Запчасти Doosan Daewoo OIL PUMP ENGINE PARTS

101

65.05101-7021

OIL PUMP ASS'Y(NO.102Ў­118)

desc: POMPE D'CHUILE

1шт.

102

65.05102-0018

HOUSING;OIL PUMP

SC: D

1шт.

103

65.05104-6065

GEAR ASS'Y;OIL PUMP

desc: . PIGNON

1шт.

106

65.05105-0044

SHAFT;OIL PUMP

desc: . ARBRE

1шт.

107

65.05104-0177

GEAR;OIL PUMP

desc: . ENSEMBLE POMPE A HUILE

1шт.

108

65.05705-6016

STRAINER ASS'Y

desc: . FILTRE

1шт.

109

06.01013-9117

BOLT M8X65

desc: . BOULON A 6 PANS

4шт.

110

06.16731-2107

WASHER;SPRING

desc: . RONDELLE ELASTIQUE

4шт.

111

65.05103-0051

COVER;OIL PUMP

SC: D

1шт.

112

65.91710-0012

RING;STOPPER

desc: . BAGUE

1шт.

113

06.22070-0913

PIN;SPLIT 4X30

desc: . GOUJON

1шт.

114

65.91305-0007

SEAT;SPRING

desc: . SIEGE

1шт.

115

65.97601-0090

SPRING;COMPRESSION

desc: . RESSORT

1шт.

116

06.31641-0222

BALL;STEEL 15/32

desc: . BILLE

1шт.

117

06.01913-3113

BOLT ASS'Y M8X20

desc: . BOULON A 6 PANS

2шт.

118

65.96601-0058

GASKET

desc: . JOINT

1шт.

119

65.05701-5636

OIL PIPE ASS'Y

SERIAL: 020917

1шт.

119

65.05701-5636A

OIL PIPE ASS'Y

SERIAL: 020918

1шт.

120

06.01923-3120

BOLT ASS'Y M8X45

desc: BOULON A 6 PANS

4шт.

121

65.05903A0002

GASKET

desc: JOINT

2шт.

122

06.01944-3215

BOLT ASS'Y M10X1.25X25

desc: BOULON A 6 PANS

2шт.

202

65.05201-0065

GEAR;OIL PUMP DRIVE

desc: PIGNON

1шт.

203

65.05207-0006

COUPLING;SLEEVE

desc: FIXATION DE POMPE

1шт.

204

65.05202-0001A

BUSH;DRIVE GEAR

desc: DOUILLE

1шт.
