Запчасти Doosan Daewoo ROTATING BEACON-FROM KOREA OPTION PARTS

-

534-00091F4

BEACON ASSY(OPT)

SC: D

-2шт.

3

2549-9098

SWITCH;ROCKER

desc: INTERRUPTEUR

1шт.

3A

K9000353

LAMP;PILOT

desc: . LAMPE

1шт.

4

2190-2036D10

INSERT;ROTATING BEACON

desc: INSERTION

1шт.

12

195-01694

BRACKET;CABIN LAMP(REAR)

desc: SUPPORT

1шт.

14

S0556453

BOLT

desc: BOULON

2шт.

15

S5102503

WASHER;SRPING M8

desc: RONDELLE

2шт.

16

2114-1898D8

WASHER

desc: RONDELLE

2шт.

17

S4012533

NUT

desc: ECROU

2шт.

18

534-00062

LAMP ASSY;ROTATING BEACON

desc: LAMPE

1шт.

19

160-00032

BUSH;BEACON MOUNTING

desc: DOUILLE

1шт.

20

195-01692

PLATE;LAMP BRACKET

desc: PLAQUE

1шт.

27

530-00237

HARNESS;REAR CABIN LAMP(OPT)

desc: HARNAIS

1шт.

28

530-00248

HARNESS;REAR LAMP JOINT

desc: HARNAIS

1шт.

29

530-00238A

HARNESS;BEACON & REAR CABIN LAMP(OPT)

desc: HARNAIS

1шт.

31

S0504453

BOLT

desc: BOULON

1шт.

32

S5102303

WASHER;SPRING

desc: RONDELLE ELASTIQUE

3шт.

33

S5010313

WASHER;PLAIN

desc: RONDELLE PLATE

1шт.
