Запчасти Doosan Daewoo AIRCONDITIONER(2)-AIRCON UNIT BODY PARTS

-

2920-1080

COOLER & HEATER ASS'Y

SC: D

-2шт.

29

2920-9044C

UNIT;AIRCON 4100 Kcal/h

SERIAL: 1-50220

1шт.

29

2920-9044G

UNIT;AIRCON

SERIAL: 50221

1шт.

29A

2538-6015

MOTOR;BLOWER 24V 15A

desc: . MOTEUR

1шт.

29B

545-00003

RESISTOR

desc: . RESISTANCE

1шт.

29C

2544-6023

RELAY 24V 10A 4P

desc: . RELAIS DEMARREUR

2шт.

29D

2544-6024

RELAY 24V 20A 5P

desc: . RELAIS DEMARREUR

1шт.

29E

2538-6016

ACT MOTOR;INTAKE 24V

desc: . MOTEUR

2шт.

29F

2538-6017

ACT MOTOR;MIX 12V

desc: . MOTEUR

1шт.

29G

2471-6050

FILTER;AIRCON GSB-30NA

desc: . FILTRE

1шт.

29H

2426-6048

VALVE;STEM

desc: . VANNE

1шт.

29I

2547-6033

SENSOR;TEMPERATURE

desc: . CAPTEUR REGIME

1шт.

29J

2530-6005

HARNESS;AIRCON UNIT

SERIAL: 1-50220

1шт.

29J

2530-6005A

HARNESS;AIRCON UNIT

SERIAL: 50221

1шт.

29K

2920-6111

EVAPORATOR 235HX224WX74T

desc: . CHAUFFAGE

1шт.

29L

2920-6112

CORE;HEATER 186HX163WX29T

desc: . CHAUFFAGE

1шт.

29M

2431-6002

LEVER;MAIN SCP1 1.2T

SERIAL: 1-50220

1шт.

29M

133-00162

LEVER;MAIN SCP1 1.2T

SERIAL: 50221

1шт.

29N

2431-6003

LEVER;SUB POLY ACETAL

desc: . LEVIER

3шт.

31

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

6шт.

32

S5102503

WASHER;SPRING

desc: RONDELLE GROWER

6шт.

33

2114-1058D29

WASHER

desc: RONDELLE

6шт.
