Запчасти Doosan Daewoo ARM PIPING-ARM 2.6M(ONE & TWO WAY) OPTION PARTS

-

2400-2139

ARM PIPING-2.6m(ONE & TWO WAY)

SC: D

1

2184-1196D87

HOSE

desc: TUYAU FLEXIBLE

2шт.

2

2140-1665

PIPE

desc: CONDUITE

2шт.

3

2420-9628

VALVE;STOP

desc: VANNE

2шт.

4

S8000291

O-RING

desc: JOINT TORIQUE

6шт.

5

S8030161

O-RING

desc: JOINT TORIQUE

6шт.

6

2181-2566D8

ADAPTER;UNION

desc: RACCORD ADAPTATEUR

2шт.

7

2181-2816D2

ELBOW

desc: COUDE

2шт.

8

2181-2817D2

CAP

desc: CHAPEAU

2шт.

9

2181-4133D6

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

10

2124-1695

CLAMP;STOP VALVE

desc: ATTACHE DE TUBE

2шт.

11

2124-1026D3

CLAMP;PIPE

desc: ATTACHE DE TUBE

4шт.

12

S5102703

WASHER;SPRING

desc: RONDELLE ELASTIQUE M12

8шт.

13

S0561353

BOLT M12X1.75X80

desc: BOULON A 6 PANS

4шт.

14

S0560953

BOLT M12X1.75X60

desc: BOULON A 6 PANS

4шт.
