Запчасти Doosan Daewoo LOCK VALVE PIPING OPTION PARTS
4A
4A
4A
26
18
19
30
17
19
31
30
31
36
21
4
3
12
11
4
20
15
16
31
30
24
6
2
4
25
6
20
15
29
15
16
30
31
16
14
28
13
7
28
7
22
34
23
25
27
32
1
33
31
9
10
16
32
15
34
32
35
-
400-00191
LOCK VALVE PIPING
SC: D
-2шт.
1
440-00090
CYLINDER;BOOM(L.H)
desc: VERIN DE FLECH
1шт.
2
440-00091
CYLINDER;BOOM(R.H)
desc: VERIN DE FLECH
1шт.
3
440-00092
CYLINDER;ARM
desc: VERIN DE BALANCIER
1шт.
4
420-00003A
VALVE;LOCK
desc: VANNE
3шт.
4A
K9000998
SEAL KIT
desc: . KIT DE JOINT
1шт.
6
2184-1062D59
HOSE PF1/4-1500L
desc: TUYAU FLEXIBLE
4шт.
7
2184-1076D118
HOSE PF1/4-1600L
desc: TUYAU FLEXIBLE
2шт.
9
2184-1060D217
HOSE PF3/8-1150L
desc: TUYAU FLEXIBLE
1шт.
10
2184-1062D78
HOSE PF3/8-1500L
desc: TUYAU FLEXIBLE
1шт.
11
2184-1046D261
HOSE PF1/4-4800L
desc: TUYAU FLEXIBLE
1шт.
12
2184-1046D260
HOSE PF1/4-4740L
desc: TUYAU FLEXIBLE
1шт.
13
2184-1046D284
HOSE PF3/8-1800L
desc: TUYAU FLEXIBLE
1шт.
14
2184-1045D206
HOSE PF3/8-2000L
desc: TUYAU FLEXIBLE
1шт.
15
S2212666
BOLT;SOCKET M10X1.5X50
desc: BOULON DE PLOT
16шт.
16
S5110613
WASHER;SPRING M10
desc: RONDELLE ELASTIQUE
16шт.
17
S2215766
BOLT;SOCKET M12X1.75X55
desc: BOULON DE PLOT
4шт.
18
S2215866
BOLT;SOCKET M12X1.75X60
desc: BOULON DE PLOT
4шт.
19
S5110703
WASHER;SPRING M12
desc: RONDELLE ELASTIQUE
8шт.
20
S8000281
O-RING
desc: JOINT TORIQUE
2шт.
21
S8000341
O-RING
desc: JOINT TORIQUE
1шт.
22
195-00294
BRACKET
desc: SUPPORT
1шт.
23
S0561353
BOLT M12X1.75X80
desc: BOULON
1шт.
24
S0515353
BOLT M12X1.75X35
desc: BOULON
2шт.
25
S5102703
WASHER;SPRING M12
desc: RONDELLE ELASTIQUE
3шт.
26
197-00020
BRACKET
desc: SUPPORT
2шт.
27
181-00020
ADAPTER 2PF1/4
desc: ADAPTEUR
1шт.
28
181-00008
TEE PF3/8X2PF1/4
desc: TE
2шт.
29
181-00007
ADAPTER PF1/4XPF3/8
desc: ADAPTEUR
2шт.
30
2181-1126D14
ADAPTER PFO1/4XPF1/4
desc: ADAPTEUR
8шт.
31
S8000111
O-RING
desc: JOINT TORIQUE
9шт.
32
S8000141
O-RING
desc: JOINT TORIQUE
3шт.
33
2181-1951D14
TEE PFO1/4XPF1/4XPF3/8
desc: TE
1шт.
34
2181-1951D16
TEE PFO3/8X2PF3/8
desc: TE
2шт.
35
2181-1951D11
TEE PFO3/8XPF3/8XPF1/4
desc: TE
1шт.
36
2124-1084D2
CLIP;BAND
desc: ATTACHE
30шт.
