Запчасти Doosan Daewoo OIL COOLER PIPING(1) BODY PARTS

-

2400-1480

OIL COOLER PIPING

SERIAL: 1-210

-2шт.

-

2400-1650

OIL COOLER PIPING

SERIAL: 211

-2шт.

1

2183-3622

PIPE;SUCTION

SERIAL: 1-997

1шт.

1

2183-3622A

PIPE;SUCTION

SERIAL: 998

1шт.

9

2185-1002D59

HOSE 650L

SERIAL: 1-997

1шт.

9

2185-1002D89

HOSE 650L

SERIAL: 998

1шт.

11

2184-1197D37

HOSE UNF1 3/16"-400L

SERIAL: 1-1945

1шт.

11

2184-1212D18

HOSE UNF1 3/16"-410L

SERIAL: 1946

1шт.

12

2184-1197D35

HOSE UNF1 3/16"-700L

desc: TUYAU FLEXIBLE

1шт.

17

S8450082

CLAMP;HOSE

desc: COLLIER

4шт.

21

2181-4133D5

ADAPTER;ORFS PF3/4"-UNF1-3/16"

desc: RACCORD ADAPTATEUR

3шт.

22

2181-2294D2

ELBOW;ORFS PF3/4"-UNF1-3/16"

desc: COUDE

1шт.

23

S8000241

O-RING P24

desc: JOINT TORIQUE P24

4шт.

24

S8030121

O-RING F12

desc: JOINT TORIQUE

4шт.

28

S8010751

O-RING G75

desc: JOINT TORIQUE G75

1шт.

29

S2215361

BOLT;SOCKET M12X1.75X35

desc: BOULON A 6 PANS CREUX

4шт.
