Запчасти Doosan Daewoo PILOT PIPING(8) BODY PARTS
3
22
2
21
12
11
17
31
12
36
15
32
35
34
33
23
45
45
-
400-01181
PILOT PIPING
SC: D
-2шт.
2
420-00343A
VALVE;REMOCON(R.H)
SERIAL: 1001-1236
1шт.
2
420-00343B
VALVE;REMOCON(R.H)
SERIAL: 1237
1шт.
3
S2205066
BOLT;SOCKET
desc: BOULON A 6 PANS
4шт.
11
S8000111
O-RING
desc: JOINT TORIQUE
6шт.
12
S8000141
O-RING
desc: JOINT TORIQUE
2шт.
15
2181-1126D7
ADAPTER PFO3/8-PF3/8
desc: ADAPTATEUR
1шт.
17
2181-1126D89
ADAPTER PFO1/4-PF3/8
desc: ADAPTATEUR
6шт.
21
2181-1702D5
ELBOW PFO3/8-PF3/8
desc: COUDE
1шт.
22
2621-2752
PLATE
desc: PLAQUE
1шт.
23
124-00226A
CLAMP;HOSE
desc: COLLIER
1шт.
31
2184-1060D151
HOSE PF3/8-1950L
desc: TUYAU FLEXIBLE
1шт.
32
2184-1060D151
HOSE PF3/8-1950L
desc: TUYAU FLEXIBLE
1шт.
33
2184-1060D147
HOSE PF3/8-2600L
desc: TUYAU FLEXIBLE
1шт.
34
2184-1060D147
HOSE PF3/8-2600L
desc: TUYAU FLEXIBLE
1шт.
35
2184-1060D147
HOSE PF3/8-2600L
desc: TUYAU FLEXIBLE
1шт.
36
2184-1060D147
HOSE PF3/8-2600L
desc: TUYAU FLEXIBLE
1шт.
45
120-00276
BOLT;SET M8X1.25X12
desc: BOULON A 6 PANS
2шт.
