Запчасти Doosan Daewoo TRAVEL PIPING TRACK PARTS
14
4
3
5
12
13
5
3
4
7
15
8
10
1
10
1
11
15
7
1
5
1
9
12
2
11
6
5
13
7
9
5
12
6
13
2
5
-
400-00113A
TRAVEL PIPING
SC: D
-2шт.
1
2184-1098D61
HOSE PF1-2150L
desc: TUYAU FLEXIBLE
4шт.
2
2181-9078
FLANGE;SPLIT 1"-5000psi
desc: BRIDE
8шт.
3
2181-9081
FLANGE;SPLIT 1"-6000psi
desc: BRIDE
8шт.
4
S2215366
BOLT;SOCKET M12X1.75X35
desc: BOULON A 6 PANS
16шт.
5
2180-1026D19
O-RING SAE1
desc: JOINT TORIQUE
8шт.
6
S2212266
BOLT;SOCKET M10X1.5X30
desc: BOULON A 6 PANS
16шт.
7
S8000181
O-RING 1BP-8
desc: JOINT TORIQUE
3шт.
8
2181-2281D10
TEE 3-PF1/2
desc: TE
1шт.
9
2184-1076D103
HOSE PF1/4-2900L
desc: TUYAU FLEXIBLE
2шт.
10
2184-1070D47
HOSE PF1/2-2100L
desc: TUYAU FLEXIBLE
2шт.
11
2181-1126D6
ADAPTER PFO1/2-PF1/2
desc: ADAPTATEUR
2шт.
12
2181-1126D14
ADAPTER PFO1/4-PF1/4
desc: ADAPTATEUR
3шт.
13
S8000111
O-RING 1BP-11
desc: JOINT TORIQUE
3шт.
14
2181-4125
TEE 1/4
desc: TE
1шт.
15
2160-4003
BUSHING;RUBBER
desc: MANCHON
2шт.
