/ / / / / ARM PIPING-ARM 2.5M(ONE & TWO WAY)
Запчасти Doosan Daewoo ARM PIPING-ARM 2.5M(ONE & TWO WAY) OPTIONAL PARTS
4
13
13
15
7
15
7
8
8
3
10
4
3
4
8
7
15
10
13
1
2
8
9
7
8
15
3
9
13
3
5
5
3
16
14
11
3
4
11
6
12
4
12
-
400-00407
ARM PIPING;ONE & TWO WAY
SC: D
-2шт.
1
140-00567A
PIPE
desc: CONDUITE
2шт.
2
2184-1196D90
HOSE
desc: TUYAU FLEXIBLE
2шт.
3
S8000381
O-RING
desc: JOINT TORIQUE
6шт.
4
2180-1026D37
O-RING
desc: JOINT TORIQUE
8шт.
5
2420-9631A
VALVE;STOP
desc: VANNE
2шт.
6
124-00170
CLAMP
desc: COLLIER
2шт.
7
2124-1693
CLAMP;PIPE
desc: ATTACHE DE TUYAU
4шт.
8
2161-2505
RUBBER
desc: CAOUTCHOUC
8шт.
9
2181-2566D9
ADAPTER
desc: RACCORD ADAPTEUR
2шт.
10
2181-4133D35
ADAPTER
desc: RACCORD ADAPTEUR
2шт.
11
2181-2816D3
ELBOW
desc: COUDE
2шт.
12
2181-2817D3
CAP
desc: CHAPEAU
2шт.
13
S0561053
BOLT M12X1.75X65
desc: BOULON A 6 PANS
8шт.
14
S0566053
BOLT M12X2.0X90
desc: BOULON A 6 PANS
4шт.
15
S5102703
WASHER;SPRING M12
desc: RONDELLE ELASTIQUE
8шт.
16
S5102903
WASHER;SPRING
desc: RONDELLE ELASTIQUE
4шт.
