/ / / / / ARM PIPING-ARM 3.5M(ONE & TWO WAY)
Запчасти Doosan Daewoo ARM PIPING-ARM 3.5M(ONE & TWO WAY) OPTION PARTS
4
13
13
15
7
15
7
8
8
3
10
4
3
4
8
7
10
15
13
1
1
2
9
8
7
8
15
3
9
13
5
3
3
5
16
14
11
3
4
11
6
12
4
12
-
400-00408A
ARM PIPING;ONE & TWO WAY
SERIAL: 1031
-2шт.
1
140-00568A
PIPE
desc: TUYAU
2шт.
2
2184-1196D93
HOSE PF1-2300L
desc: TUYAU FLEXIBLE
2шт.
3
S8000381
O-RING
desc: JOINT TORIQUE
6шт.
4
2180-1026D37
O-RING
desc: JOINT TORIQUE
8шт.
5
2420-9631A
VALVE;STOP
desc: VANNE
2шт.
6
124-00170
CLAMP;STOP VALVE
desc: ATTACHE DE VANNE
2шт.
7
2124-1693
CLAMP;PIPE
desc: ATTACHE DE TUBE
4шт.
8
2161-2505
RUBBER
desc: CAOUTCHOUC
8шт.
9
2181-2566D9
ADAPTER
desc: RACCORD ADAPTATEUR
2шт.
10
2181-4133D35
ADAPTER
desc: RACCORD ADAPTATEUR
2шт.
11
2181-2816D3
ELBOW
desc: ECROU
2шт.
12
2181-2817D3
CAP
desc: CHAPEAU
2шт.
13
S0561053
BOLT
desc: BOULON A 6 PANS
8шт.
14
S0566053
BOLT
desc: BOULON A 6 PANS
4шт.
15
S5102703
WASHER;SPRING
desc: RONDELLE ELASTIQUE
8шт.
16
S5102903
WASHER;SPRING
desc: RONDELLE ELASTIQUE
4шт.
