Запчасти Doosan Daewoo MAIN PIPING FOR BREAKER OPTION PARTS

-

2400-7065

MAIN PIPING FOR BREAKER

SERIAL: 6090

-2шт.

11

2180-1026D19

O-RING SAE1"

desc: JOINT TORIQUE

1шт.

15

S2212361

BOLT;SOCKET M10X1.5X35

desc: BOULON A 6 PANS CREUX

4шт.

22

2183-3811B

PIPE

desc: CONDUITE

1шт.

23

2181-1126D25

ADAPTER PFO1XPF1

desc: RACCORD ADAPTATEUR

1шт.

24

S8000291

O-RING P29

REP_PNO: 8202-023

1шт.

25

2124-1026D3

CLAMP;PIPE

desc: ATTACHE DE TUBE

1шт.

26

S0560953

BOLT M12X1.75X60

desc: BOULON A 6 PANS

1шт.

27

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

5шт.

28

S0560553

BOLT M12X1.75X40

desc: BOULON A 6 PANS

4шт.

29

2114-1058D30

WASHER

desc: RONDELLE

4шт.

30

2183-3810A

PIPE

desc: CONDUITE

1шт.

48

2195-3719

BRACKET

desc: SUPPORT

1шт.
