Запчасти Doosan Daewoo BY-PASS VALVE HYDRAULIC PARTS

|$1

2420-9299

VALVE;BY PASS

SERIAL: 1-288

1шт.

1

CH41587

BLOCK

desc: . BLOC CYLINDRES

1шт.

2

3RRRRT218

RING;RETAINING

desc: . BAGUE DE SOUTIEN

2шт.

3

3101847

GUIDE;VALVE

desc: . GUIDE DE SOUPAPE

2шт.

4

8H41624

POPPET

desc: . SOUPAPE SOULEVANTE

2шт.

5

ASV013862

SPRING(1 BAR)

desc: . RESSORT

1шт.

6

ASV013861

SPRING(3 BAR)

desc: . RESSORT

1шт.

7

AH41590

RETAINER;SPRING

desc: . RACCORD ADAPTATEUR

1шт.

8

8022N7073

O-RING

desc: . JOINT TORIQUE

2шт.

9

8014282

SPRING(2.5BAR)

desc: . RESSORT

1шт.
