Запчасти Doosan Daewoo INTAKE MANIFOLD ENGINE PARTS
119
115
120
118
117
118
101
103
104
114
110
119
120
110
102
102
102
115
111
103
110
121
102
122
101
106
105
110
109
108
106
107
101
65.08201-5250A
MANIFOLD;INTAKE
desc: COLLECTEUR
2шт.
102
06.01923-3132
BOLT ASS'Y M8X110
desc: BOULON A 6 PANS
8шт.
103
06.01923-3129
BOLT ASS'Y M8X90
desc: BOULON A 6 PANA
8шт.
104
65.08902C0078
GASKET;INTAKE MANIFOLD
desc: JOINT
8шт.
105
65.08202-5039
PIPE;EQUALIZING
desc: TUYAU
1шт.
106
06.01923-3226
BOLT ASS'Y M10X75
desc: BOULON A 6 PANS
4шт.
107
06.01013-9222
BOLT;HEX. M10X1.5X85
desc: BOULON A 6 PANS
2шт.
108
06.15010-2312
WASHER;PLAIN
desc: RONDELLE
2шт.
109
06.16731-2108
WASHER;SPRING
desc: RONDELLE
2шт.
110
65.08902A0057
GASKET
desc: JOINT
4шт.
111
65.08202-0080
FLANGE;INLET(L.H.)
desc: BRIDE
1шт.
114
65.08202-0225
FLANGE;INLET(R.H.)
desc: BRIDE
1шт.
115
06.01923-3218
BOLT ASS'Y M10X35
desc: BOULON A 6 PANS
6шт.
117
65.08220-0002A
PIPE;CONNECTION
desc: TUYAU
2шт.
118
65.96501-0058
O-RING
desc: JOINT TORIQUE
4шт.
119
65.90310-0050B
SCREW. PLUG M20X1.5
desc: TUYAU
2шт.
120
06.56190-0715
SEAL RING A20X26
desc: JOINT TORIQUE
2шт.
121
65.90310-0048
PLUG SCREW M10X1.5
desc: SUPPORT
1шт.
122
06.56180-0714
SEAL RING A10X15
desc: BOULON A 6 PANS
1шт.
