Запчасти Doosan Daewoo ARM PIPING-ARM 2.9M(ONE & TWO WAY) OPTION PARTS

-

400-00060

ARM PIPING-ONE & TWO WAY

SC: D

-2шт.

1

2420-9631

VALVE;STOP

desc: VANNE

2шт.

2

2181-2816D3

ELBOW

desc: COUDE

2шт.

3

S8000381

O-RING

desc: JOINT TORIQUE

6шт.

4

140-00040

PIPE;ARM

desc: TUYAU

2шт.

5

2181-2817D3

CAP

desc: CHAPEAU

2шт.

6

2180-1026D37

O-RING

desc: JOINT TORIQUE

8шт.

7

2181-2566D9

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

8

S0565861

BOLT M16X2.0X80

desc: BOULON A 6 PANS

4шт.

9

2181-4133D35

ADAPTER

desc: RACCORD ADAPTEUR

2шт.

10

2184-1196D93

HOSE PF1 1/4-2300L

desc: TUYAU FLEXIBLE

2шт.

11

2124-1697

CLAMP

desc: ATTACHE DE TUYAU

2шт.

12

S5102901

WASHER;SPRING

desc: RONDELLE ELASTIQUE M16

8шт.

13

S0566161

BOLT M16X2.0X95

desc: BOULON A 6 PANS

4шт.

14

2124-1551

CLAMP;PIPE

desc: ATTACHE DE TUYAU

4шт.
