Запчасти Doosan Daewoo CAMSHAFT & VALVE ENGINE PARTS

1

894127-7974

CAM SHAFT

desc: ARBRE A CAMES

1шт.

4

894133-2751

VALVE;INLET

desc: VANNE

4шт.

5

894247-8751

VALVE;EXHAUST

desc: VANNE

4шт.

9

894324-3360

GEAR;CAM SHAFT

desc: PIGNON

1шт.

10

894110-4801

PLATE;THRUST

desc: PLAQUE

1шт.

11

050040-8160

BOLT M8X16

desc: BOULON A 6 PANS

2шт.

14

908000-7180

KEY;CAM SHAFT

desc: KEY

1шт.

28

509000-0690

BOLT;CAM PULLEY

desc: BOULON A 6 PANS

1шт.

53

894152-3460

SHAFT;ROCKER ARM

desc: ARBRE

1шт.

55

912626-0050

PLUG;ROCKER SHAFT END

desc: BOUCHON

2шт.

56

909180-0190

RING;SNAP

desc: BAGUE CIRCLIPS

2шт.

65

512565-0040

COLLAR;SPLIT

desc: RONDELLE DE BUTEE

16шт.

69

894252-5361

SPRING;VALVE OUTER

desc: RESSORT

8шт.

71

894133-7312

SEAT;SPRING OD=32.8

desc: SIEGE DE RESSORT

8шт.

71A

512563-0010

SEAT;SPRING OD=34

desc: SIEGE DE RESSORT

8шт.

78

894125-3440

ARM;ROCKER

desc: BALANCIER

8шт.

81

894152-2831

SCREW M8X30

desc: VIS

8шт.

83

909111-5080

NUT

desc: ECROU

8шт.

84

894152-3451

BRACKET;ROCKER SHAFT

desc: SUPPORT

4шт.

85

894433-3020

BOLT;BRACKET M10X60

desc: BOULON A 6 PANS

1шт.

87

894433-3040

BOLT;ROCKER SHAFT M8X15

desc: BOULON A 6 PANS

3шт.

88

894143-2020

ROD;PUSH

desc: TIGE

8шт.

89

894438-3050

TAPPET;VALVE

desc: TAPPET

8шт.

94

909164-0100

WASHER;PLAIN

desc: RONDELLE PLATE

4шт.

104

894109-7061

BOLT M12X67

desc: BOULON A 6 PANS

1шт.

106

512519-0021

WASHER;IDLE GEAR SHAFT

desc: RONDELLE PLATE

1шт.

109

894109-9131

SHAFT;IDLE GEAR

desc: ARBRE DE PIGNON

1шт.

113

897147-3340

GEAR;IDLE

desc: PIGNON

1шт.

226

894433-3030

SPRING;ROCKER ARM

desc: RESSORT

3шт.

305

894110-2710

BEARING;IDLE SHAFT

desc: PALIER

1шт.
