COOLING SYSTEM(FAN.WATER & OIL)

Запчасти Doosan Daewoo COOLING SYSTEM(FAN.WATER & OIL) ENGINE PARTS

25-3
1
32-2
38-1
18
3
7
26
14
38
29
15
30
34
33
39
8
10
40-1
12
11
48
45
36
35
21
37
22
51
20
50
43
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

894338-8480

WATER PUMP

desc: POMPE A EAU

1шт.

3

894322-7941

REPAIR KIT;WATER PUMP

desc: PIECES DE RECHANGE

1шт.

7

894250-1630

IMPELLER

desc: TURBINE

1шт.

8

894110-5600

UNIT BEARING

desc: PALIER

1шт.

10

894422-3260

SEAL UNIT

desc: JOINT PARE-POUSSIERES

1шт.

11

894452-0910

CENTER

desc: CENTER

1шт.

12

913639-0010

THROWER

desc: THROWER

1шт.

14

909814-0141

SET SCREW

desc: VIS

1шт.

15

909150-5080

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

18

894178-0810

PACKING;PUMP TO BLOCK

desc: JOINT

1шт.

20

509000-0841

BOLT;SEMS. 55L

desc: BOULON A 6 PANS

5шт.

21

904110-8220

STUD;WATER PUMP FIX

desc: GOUJON

2шт.

22

894224-8290

NUT;WATER PUMP FIX

desc: ECROU

2шт.

25-3

894254-6011

PIPE;WATER OUTLET

desc: CONDUITES

1шт.

26

894365-6741

PACKING;OUTLET PIPE

desc: JOINT

1шт.

29

894214-9620

THERMOSTAT

desc: THERMOSTAT

1шт.

30

894428-8120

HOUSING;THERMOSTAT

desc: CARTER

1шт.

32-2

894109-6811

HOSE;RUBBER BY PASS

desc: TUYAU FLEXIBLE

1шт.

33

909715-0531

CLIP;BY PASS HOSE

desc: ATTACHE

2шт.

34

894365-6750

PACKING;HOUSING

desc: JOINT

1шт.

35

050040-8300

BOLT;SEMS. HOUSING

desc: BOULON A 6 PANS

3шт.

35

050140-8300

BOLT;OUTLET

desc: BOULON A 6 PANS

2шт.

35

050040-8700

BOLT;SEMS.HOUSING

desc: BOULON A 6 PANS

2шт.

36

894427-3602

PULLEY;COOLING FAN D130

desc: POULIE

1шт.

37

913642-0780

SPACER;FAN

desc: BAGUE

1шт.

38

509605-0050

PLUG;THERMOSTAT PT3/8

desc: BOUCHON

2шт.

38-1

909661-0050

PLUG;THERMOSTAT M16

desc: BOUCHON

1шт.

39

909571-3160

PACKING;PLUG

desc: JOINT

1шт.

40-1

894342-6180

FAN D450 7 BLADE

desc: VENTILATEUR

1шт.

43

050040-8450

BOLT;SEMS FAN TO PULLEY

desc: BOULON A 6 PANS

4шт.

45

894479-1010

BELT;COOLING 1041L

desc: COURROIE

1шт.

48

894434-0711

PIPE;WATER INLET

desc: CONDUITES

1шт.

50

894365-6762

PACKING;INLET PIPE

desc: JOINT

1шт.

51

050040-8220

BOLT;SEMS INLET PIPE

desc: BOULON A 6 PANS

2шт.
