Запчасти Hyundai R280LC TRAVEL HYDRAULIC PIPING(LC)

E231-0187

E231-0187-Hose Assy

31E1-0001

31E1-0001-Turning Joint

E131-0154

E131-0154-Hose Assy

1

31E1-0612

31E1-0612-Turning Joint

10

E131-0506

E131-0506-Hose Assy

11

E131-0507

E131-0507-Hose Assy

13

E131-0156

E131-0156-Hose Assy

14

E131-0286

E131-0286-Hose Assy

16

E131-0038

E131-0038-Tee

17

E231-0120

E231-0120-Tee

18

P010-110004

P010-110004-Connector

19

P010-110002

P010-110002-Connector

2

33E2-1001

33E2-1001-Pipe Assy

20

CO0418A

CO0418A-O-Ring

21

S631-018001

S631-018001-O-Ring

22

S631-011001

S631-011001-O-Ring

23

S107-100302

S107-100302-Bolt-Socket

24

S107-120302

S107-120302-Bolt-Socket

25

S017-160454

S017-160454-Bolt-Hex

26

S017-100604

S017-100604-Bolt-Hex

27

S205-161004

S205-161004-Nut-Hex

28

S411-100004

S411-100004-Washer-Spring

29

S411-160004

S411-160004-Washer-Spring

3

33E2-1002

33E2-1002-Pipe Assy

30

E231-0123

E231-0123-Clamp Pipe-C

31

P173-160104

P173-160104-Flange-Split

4

33E2-1003

33E2-1003-Pipe Assy

5

33E2-1004

33E2-1004-Pipe Assy

6

E231-5009

E231-5009-Hose Assy

7

E231-5008

E231-5008-Hose Assy
