002(A)
1132402322
ELEMENT; OIL FILTER
200007-
2шт.
013
1132690090
VALVE; RELIEF
200007-
1шт.
021(A)
1096301410
GASKET; PLUG
200007-
2шт.
021(B)
1096231790
GASKET; PLUG
200007-
3шт.
045
1133412310
COVER; OIL PORT
200007-
1шт.
047
1217790010
RING; SEAL,THERMO VLV
200007-
1шт.
100
9992023140
PLUG; OIL COOLER
200007-200805
2шт.
100
8980429440
PLUG; OIL COOLER
200806-201009
2шт.
100
9098621560
PLUG; OIL COOLER
201010-
2шт.
102
1217003570
COOLER ASM; OIL
A 200007-200504
1шт.
102
8980037905
COOLER ASM; OIL
200505-
1шт.
103(A)
0281810300
BOLT; OIL COOLER
200007-200512
17шт.
103(A)
0281510300
BOLT; OIL COOLER
200601-
17шт.
103(B)
8943445401
BOLT; OIL COOLER
200007-
8шт.
103(C)
0281860110
BOLT; OIL COOLER
200007-200512
1шт.
103(C)
0281560110
BOLT; OIL COOLER
200601-
1шт.
110
1217210985
BODY; CASE,OIL COOLER
200007-
1шт.
111
1217230670
CORE; OIL COOLER
200007-200504
1шт.
111
8980481401
CORE; OIL COOLER
200505-
1шт.
114
1217290861
PLATE; BAFFLE,OIL COOLER
200007-
1шт.
115
0912501100
NUT; ELEMENT
200007-200504
4шт.
115
0911501100
NUT; ELEMENT
A 200505-200602
4шт.
115
0911801100
NUT; ELEMENT
200603-
4шт.
175
1096300870
GASKET; DRAIN
200007-
1шт.
196
1217700040
THERMOSTAT; OIL COOLER
200007-
1шт.
197
1096234190
GASKET; THERMOSTAT
200007-
1шт.
198
1217260532
JOINT; THERMOSTAT
200007-
1шт.
199
0208010350
BOLT; JOINT,THERMOSTAT
200007-200504
2шт.
199
0501410350
BOLT; JOINT,THERMOSTAT
A 200505-200512
2шт.
199
0506410350
BOLT; JOINT,THERMOSTAT
200601-
2шт.
202
9099147010
HOSE; WATER,WATER DRAIN
200102-
1шт.
288(A)
1096040230
PLUG; OIL DRAIN
200007-
3шт.
321(B)
1096234790
GASKET; OIL FILTER TO C/BL
200007-
2шт.
324
0281810800
BOLT; COVER,OIL PORT
A 200007-200512
4шт.
324
0281510800
BOLT; COVER,OIL PORT
200601-
4шт.
352
8972221250
ADAPTER; OIL FILTER
200007-
2шт.
380
1096600111
CONNECTOR; WATER
200007-
1шт.
381
1096230590
GASKET; VLV
200007-
1шт.
444(A)
1217290931
GASKET; ELEMENT TO BODY
200007-200504
2шт.
444(A)
8976066400
GASKET; ELEMENT TO BODY
200505-
2шт.
444(B)
8976066410
GASKET; ELEMENT TO BODY
200505-
2шт.
462
5097070041
CLIP; HOSE,DRAIN
200007-
1шт.
469(A)
1096234780
GASKET; OIL COOLER TO C/BL
200007-
2шт.
469(B)
1096234790
GASKET; OIL COOLER TO C/BL
200007-
2шт.
469(C)
1112191860
GASKET; OIL COOLER TO C/BL
A 200007-200109
1шт.
469(C)
1112192050
GASKET; OIL COOLER TO C/BL
200110-
1шт.
496(A)
1132010192
FILTER ASM; OIL
200007-
1шт.
497
1137214963
PIPE; WATER DRAIN
200007-
1шт.
498
0281810200
BOLT; WATER PIPE
A 200007-200512
1шт.
498
0281510200
BOLT; WATER PIPE
200601-
1шт.
499(A)
1217290854
SUPPORT; THERMOSTAT
200007-
1шт.
499(B)
1217290941
SUPPORT; THERMOSTAT
200007-
1шт.
500
9091606100
WASHER; PL,JOINT
200007-200504
2шт.
501
9091505100
WASHER; LK,JOINT
200007-200504
2шт.
502
1217220400
COVER; THERMOSTAT
200007-
1шт.
503
1217290890
BOLT; COVER
A 200007-200504
4шт.
503
8980147630
BOLT; COVER
200505-201111
4шт.
503
0280508160
BOLT; COVER
201112-
4шт.
504
1217290900
WASHER; PL,COVER
200007-200504
4шт.
506
9034866080
SCREW; BAFFLE
200007-200504
10шт.
506
1090300360
SCREW; BAFFLE
200505-201111
10шт.
506
8981978290
SCREW; BAFFLE
201112-
10шт.
507
1217290920
WASHER; LK,BAFFLE
200007-200504
10шт.
