1
AT147239
Oil Line
1шт.
2
T76938
O-Ring
23.520 X 1.780 mm (0.926" X 0.070")
1шт.
3
AT147237
Hydraulic Hose
1шт.
4
T78313
O-Ring
32.920 X 3.530 mm (1.296" X 0.139")
5шт.
5
T60983
Flange Fitting
1шт.
6
0413619
Bolt
(SUB FOR AT154591)
4шт.
7
U12547
O-Ring
23.470 X 2.946 mm (0.924" X 0.116")
1шт.
8
38H1216
Adapter Fitting
1шт.
10
AT183796
Hydraulic Hose
1" X 311 mm (12-1/4") X 36.5252"
1шт.
11
T111207
Bolt
M12 X 140
2шт.
12
19M8519
Screw
M12 X 120
2шт.
13
T107068
Flange Fitting
4шт.
14
T145378
Fitting
2шт.
15
AT152186
Hyd Actuated Control Valve
1шт.
16
AT35121
Elbow Fitting
2шт.
17
R26448
O-Ring
11.887 X 1.981 mm (0.468" X 5/64")
2шт.
18
AT126601
Hydraulic Hose
9/16" X 1250 mm (49-1/4") X 9/16"
2шт.
19
T164046
Bracket
1шт.
20
19M8395
Screw
M12 X 40
2шт.
21
14M7275
Nut
M12
4шт.
22
AT36921
Tee Fitting
2шт.
23
AE24616
Elbow Fitting
1шт.
24
14M7275
Nut
M12
1шт.
25
12H301
Lock Washer
1/2"
4шт.
26
19M7361
Cap Screw
M12 X 50
1шт.
27
19M7403
Cap Screw
M12 X 35
3шт.
28
T164047
Bracket
1шт.
29
4202103
Clamp
(SUB FOR TH108302)
1шт.
30
AT196907
Kit
(SUB FOR AT185198)WHOLEGOO DS (BOOM REDUCED DRIFT KIT)
1шт.
