3
4189601
Adapter Fitting
(SUB FOR AT107394)
4шт.
3A
AT318035
O-Ring
(SUB FOR 4506424, TH100055)
1шт.
4
4394152
Adapter Fitting
(SUB FOR AT250100)
4шт.
5
T76938
O-Ring
23.520 X 1.780 mm (0.926" X 0.070")
8шт.
7
4390093
Hydraulic Hose
(SUB FOR AT250085)
2шт.
8
4221224
Tee Fitting
(SUB FOR AT318018 AND AT154156)
1шт.
8A
4506418
O-Ring
(SUB FOR U46489)
1шт.
9
4154672
Elbow Fitting
(SUB FOR TH101008)
2шт.
9A
4506418
O-Ring
(SUB FOR U46489)
1шт.
11
4390092
Hydraulic Hose
(SUB FOR AT250084)
2шт.
12
4200465
Adapter Fitting
(SUB FOR TH108328)
2шт.
12A
M800650
Packing
1шт.
13
4200468
Adapter Fitting
(SUB FOR AT126336)
2шт.
13A
CH11570
O-Ring
13.800 X 2.400 mm (0.543" X 3/32")
1шт.
15
4396013
Bushing
(SUB FOR AT250104)
2шт.
18
4202103
Clamp
(SUB FOR TH108302)
2шт.
19
9736782
Clamp
(SUB FOR AT201191)
2шт.
20
19M8348
Cap Screw
M12 X 65
2шт.
12H301
Lock Washer
1/2"
2шт.
21
H77698
Tie Band
6шт.
23
T78313
O-Ring
32.920 X 3.530 mm (1.296" X 0.139")
4шт.
24
4085560
Flange Fitting
(SUB FOR TH101960)
8шт.
26
19M9163
Screw
M12 X 40 (SUB FOR J781240)
16шт.
28
4403820
Hydraulic Hose
(SUB FOR AT250134)
2шт.
29
4403819
Hydraulic Hose
(SUB FOR AT250133)
2шт.
