Запчасти John Deere 5C ZTS 88 - Air Conditioner Components 1830 HEATING AND AIR CONDITIONING

0

Air Conditioner Kit

(WHOLEGOODS) ( AT305610 NLA)

1шт.

1

AT306877

Air Conditioner

1шт.

AT307724

Blower Motor

1шт.

AT307725

Thermostat

1шт.

AT262539

Resistor

(SUB FOR 842949600)

1шт.

2

843026000

Spool Valve

(EXPANSION)

1шт.

3

AT306879

Compressor

(ALSO ORDER RE12362, R78063, R78060)

1шт.

4

AT306878

Vapor Condenser

1шт.

5

AT306881

Receiver-Dryer

1шт.

6

AT306873

Hose

1шт.

7

AT306871

Hose

1шт.

8

AT306874

Hose

1шт.

9

AT306872

Hose

1шт.

10

RE60888

Pressure Switch

1шт.

11

RE155938

Pressure Switch

1шт.

12

842829400

Relay

1шт.

13

AR21999

Hose Clamp

2шт.

14

T205268

Bracket

(RECEIVER-DRYER)

1шт.

15

AT306880

Wiring Harness

1шт.

16

AT197520

Switch

1шт.

17

T205276

Label

1шт.

18

T205280

Bracket

(NOT NEEDED ON 27CZTS) (CONDENSER)

2шт.

19

T205281

Bracket

4шт.

20

T205269

Bracket

(RECEIVER-DRYER)

1шт.

21

T205273

Cap

4шт.

22

AT220817

Knob

(FOR USE WITH AT197520) (NOT ILLUSTRATED)

1шт.

23

RE12362

Electrical Connector Assy

(STARTER JUMPER HARNESS)

1шт.

R78060

Elec. Connector Terminal

1шт.

24

R78063

Elec. Connector Seal

(PACKAGE OF 40) (16 GUAGE WIRE)

1шт.
