0
6016908
Hydraulic Reservoir
(SUB FOR AT251537)
1шт.
4
4339554
Strainer
(SUB FOR AT251238)
1шт.
5
4300509
Adapter Fitting
(SUB FOR AT251219)
1шт.
6
AT264419
O-Ring
(SUB FOR U46456 OR A810085)
1шт.
8
19M7402
Cap Screw
M10 X 25
4шт.
12M7066
Lock Washer
10 mm
4шт.
11
2038091
Manifold
(SUB FOR AT251116)
1шт.
12
4255212
Check Valve
(SUB FOR AT251177)
1шт.
13
40M7123
Snap Ring
1шт.
14
19M7695
Screw
M10 X 20
4шт.
18
Filter
(RETURN) (NOT AVAILABLE FOR SERVICE)
1шт.
18A
4294132
Hydraulic Filter
(SUB FOR AT251211)
1шт.
18B
4294133
Rod
(SUB FOR AT251212)
1шт.
19
8063384
Cover
(SUB FOR AT251565)
1шт.
20
T110443
O-Ring
109.400 X 3.100 mm (4.307" X 0.122")
1шт.
21
12M7066
Lock Washer
10 mm
4шт.
22
19M7402
Cap Screw
M10 X 25
5шт.
12M7066
Lock Washer
10 mm
5шт.
23
CH17154
Packing
1шт.
25
4272375
Filler Cap
(SUB FOR AT251180)
1шт.
28
8050296
Level Gauge
(SUB FOR AT251561)
1шт.
28A
4100967
Bolt
(SUB FOR TH101894)
2шт.
28B
Level Gauge
( 3118238 NLA)
1шт.
29
449558
Washer
(SUB FOR TH100675)
4шт.
30
Hose
(VINYL) (CUT TO LENGTH FROM T Y22558 BULK MATERIAL) (900 MM)
1шт.
31
94-2023
Fitting Plug
(SUB FOR TH100667)
1шт.
33
19M8011
Cap Screw
M12 X 30
4шт.
34
24M7047
Washer
13 X 24 X 2.500 mm
4шт.
37
4129457
Adapter Fitting
(SUB FOR AT251163)
1шт.
37A
TH101926
O-Ring
28.700 X 3.500 mm (1.130" X 0.138")
1шт.
38
4392021
Adapter Fitting
(SUB FOR AT251334)
1шт.
38A
TH101926
O-Ring
28.700 X 3.500 mm (1.130" X 0.138")
1шт.
39
4392020
Elbow Fitting
(SUB FOR AT251333)
1шт.
39A
970860
O-Ring
37.700 X 3.500 mm (1-31/64" X 0.138") (SUB FOR TH104634)
1шт.
