1
113-04-32250
TUBE
SN: 32001-UP
1шт.
1
113-04-32260
TUBE,(FOR ADDITIONAL FUEL STRAINER)
SN: 32001-UP
1шт.
2
113-04-22220
TUBE
SN: 32001-UP
1шт.
3
07260-20956
HOSE
SN: 32001-UP
1шт.
4
07281-00197
CLAMP
SN: 32001-UP
2шт.
5
07206-11014
BOLT
SN: 32001-UP
1шт.
6
07005-01412
GASKET
SN: 32001-UP
2шт.
7
08034-00519
BAND
SN: 32001-UP
1шт.
|$8
113-54-00150
SIDE COVER ASS'Y,R.H. (FOR WATER SEPARATOR)
SN: 32001-UP
1шт.
|$9
113-54-00160
SIDE COVER ASS'Y,R.H. (FOR PERFORATED TYPE)
SN: 32001-UP
1шт.
8
113-54-39510
COVER,(FOR WATER SEPARATOR)
SN: 32001-UP
1шт.
8
113-54-39550
COVER,(FOR PERFORATED TYPE)
SN: 32001-UP
1шт.
9
113-54-39520
COVER,(FOR WATER SEPARATOR)
SN: 32001-UP
1шт.
9
113-54-39560
COVER,(FOR PERFORATED TYPE)
SN: 32001-UP
1шт.
10
04050-11612
PIN
SN: 32001-UP
2шт.
11
113-54-39530
PIN
SN: 32001-UP
1шт.
12
175-40-22240
SPRING
SN: 32001-UP
1шт.
13
01640-21323
WASHER
SN: 32001-UP
1шт.
14
04205-10620
PIN
SN: 32001-UP
1шт.
15
04050-11612
PIN
SN: 32001-UP
1шт.
