Запчасти Komatsu D32E-1 СИДЕНЬЕ КРЕПЛЕНИЕ - БЕЗ РЕМЕНЬ БЕЗОПАСНОСТИ RETRACTOR С СИСТЕМОЙ ROPS SUPERSTRUCTURE

1

SEAT, SUSPENSION (SEE PG 13-030)

-29шт.

|$1

25 552 R1

WASHER, FLAT - 5/16

4шт.

|$2

25 520 R1

NUT, HEX - 5/16NC

4шт.

|$3

1300 487 H91

SEAT AND SUPPORTS

-54шт.

2

1306 182 H1

ARM REST

2шт.

|$5

24 839 R1

BOLT, HEX - 3/8NCx3/4

4шт.

|$6

25 534 R1

WASHER, FLAT - 3/8

4шт.

3

1306 181 H1

BRACKET, MOUNTING

2шт.

|$8

24 839 R1

BOLT, HEX - 3/8NCx3/4

4шт.

|$9

25 534 R1

WASHER, FLAT - 3/8

4шт.

4

1304 125 H91

PLATE, SEAT MOUNTING

1шт.

|$11

24 840 R1

BOLT, HEX - 3/8NCx1

6шт.

|$12

25 553 R1

WASHER, FLAT - 3/8

6шт.

|$13

24 860 R1

BOLT, HEX - 1/2NCx1

3шт.

|$14

25 555 R1

WASHER, FLAT - 1/2

3шт.

5

1300 620 H91

SUPPORT, FRONT SEAT

1шт.

|$16

24 848 R1

BOLT, HEX - 7/16NCx3/4

4шт.

|$17

25 553 R1

WASHER, FLAT - 3/8

4шт.

6

3071 294 R1

BOSS, MOUNTING - TUBE CLAMP

1шт.

7

1300 689 H1

BAR, SEAT MOUNTING

2шт.

|$20

24 840 R1

BOLT, HEX - 3/8NCx1

4шт.

|$21

25 553 R1

WASHER, FLAT - 3/8

4шт.

8

636 888 C3

BELT, SEAT

1шт.

|$23

24 864 R1

BOLT, HEX - 1/2NCx2

2шт.

|$24

25 555 R1

WASHER, FLAT - 1/2

4шт.

|$25

9412 230

NUT, LOCK - 1/2NC

2шт.

9

1287 385 H1

SLEEVE, EXTRUDED

2шт.

10

610 395 R1

SPACER, PIPE

4шт.

|$$29

-1шт.

|$29

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY.

-1шт.

|$$31

-1шт.
