1
195-21-12611
MAIN FRAME
SN: 10838-UP
1шт.
|1
195-21-11308
MAIN FRAME
SN: 9001-10837
1шт.
|1
195-21-11307
MAIN FRAME
SN: 5001-9000
1шт.
|1
0
MAIN FRAME
SN: 4001-5000
1шт.
|1
195-21-11305
MAIN FRAME
SN: 3301-4000
1шт.
|1
195-21-29101
MAIN FRAME,(FOR INSIDE FRAME)
SN: 9001-UP
1шт.
|1
195-21-29100
MAIN FRAME,(FOR INSIDE FRAME)
SN: 5385-9000
1шт.
2
07044-13620
PLUG
SN: 1632-UP
3шт.
3
07000-43022
O-RING
SN: 1632-UP
3шт.
4
175-21-32170
COVER
SN: 1010-UP
1шт.
5
07000-45195
O-RING
SN: 1010-UP
1шт.
6
01010-62040
BOLT
SN: 1067-UP
6шт.
7
01643-32060
WASHER
SN: 1010-UP
6шт.
8
07030-00252
BREATHER
SN: 1010-UP
2шт.
9
07350-00215
NIPPLE
SN: 1010-UP
2шт.
10
195-21-11242
COVER
SN: 1632-UP
1шт.
11
01580-01210
NUT
SN: 1632-UP
5шт.
12
01602-01236
WASHER
SN: 1632-UP
5шт.
13
195-21-11321
PLATE
SN: 1632-UP
1шт.
14
01010-80816
BOLT
SN: 1632-UP
5шт.
15
01602-00825
WASHER
SN: 1632-4000
5шт.
16
01643-30823
WASHER
SN: 1632-UP
5шт.
17
195-21-12380
O-RING
SN: 1632-UP
1шт.
18
195-21-11173
GASKET
SN: 13664-UP
1шт.
|18
0
GASKET
SN: 1632-13663
1шт.
19
01010-81855
BOLT
SN: 1067-UP
20шт.
20
01643-31845
WASHER
SN: 1055-UP
20шт.
21
195-15-11330
PIN,DOWEL
SN: 1010-UP
1шт.
22
07049-01215
PLUG
SN: 3301-UP
6шт.
23
07049-03949
PLUG,(USED WHEN RIPPER EQUIPPED)
SN: 3301-UP
4шт.
|23
07049-03949
PLUG,(USED WHEN DRAWBAR EQUIPPED)
SN: 3301-UP
12шт.
24
07049-02025
PLUG
SN: 3301-UP
2шт.
25
07049-01620
PLUG
SN: 9001-UP
2шт.
1
195-21-12611
MAIN FRAME
|1
195-21-11308
MAIN FRAME
|1
195-21-11307
MAIN FRAME
|1
195-21-11306
MAIN FRAME
|1
195-21-11305
MAIN FRAME
|1
195-21-29101
MAIN FRAME,(FOR INSIDE FRAME)
|1
195-21-29100
MAIN FRAME,(FOR INSIDE FRAME)
2
07044-13620
PLUG
3
07000-43022
O-RING
4
175-21-32170
COVER
5
07000-45195
O-RING
6
01010-62040
BOLT
7
01643-32060
WASHER
8
07030-00252
BREATHER
9
07350-00215
NIPPLE
10
195-21-11242
COVER
11
01580-01210
NUT
12
01602-01236
WASHER
13
195-21-11321
PLATE
14
01010-80816
BOLT
15
01602-00825
WASHER
16
01643-30823
WASHER
17
195-21-12380
O-RING
18
195-21-11173
GASKET
|18
195-21-11153
GASKET
19
01010-81855
BOLT
20
01643-31845
WASHER
21
195-15-11330
PIN,DOWEL
22
07049-01215
PLUG
23
07049-03949
PLUG,(USED WHEN RIPPER EQUIPPED)
|23
07049-03949
PLUG,(USED WHEN DRAWBAR EQUIPPED)
24
07049-02025
PLUG
25
07049-01620
PLUG
