|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$7
195-22-71003
STEERING ASS'Y
SN: (108657)-UP
1шт.
|$8
195-22-71002
STEERING ASS'Y
SN: 55008-(108656)
1шт.
|$9
0
STEERING ASS'Y
SN: 55001-55007
1шт.
|$$5
(195-22-81310(4),07002-62034(4))
-1шт.
|$11
195-22-71053
STEERING ASS'Y,(WITH VHMS)
SN: (108657)-UP
1шт.
|$12
195-22-71052
STEERING ASS'Y,(WITH VHMS)
SN: 55008-(108656)
1шт.
|$13
195-22-71051
STEERING ASS'Y,(WITH VHMS)
SN: 55001-55007
1шт.
|$$9
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F2370-51C0 TO F2370-60C0.
-1шт.
|$17
195-22-72005
VALVE ASS'Y
SN: (108657)-UP
1шт.
|$18
195-22-72004
VALVE ASS'Y
SN: .-(108656)
1шт.
|$19
195-22-72003
VALVE ASS'Y
SN: 55001-.
1шт.
|$$13
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F2370-58C0 TO F2370-60C0.
-1шт.
|$21
195-22-82100
VALVE ASS'Y
SN: (108657)-UP
1шт.
|$22
195-22-72101
VALVE ASS'Y
SN: 55001-(108656)
1шт.
1
0
VALVE BODY
SN: (108657)-UP
1шт.
1
0
VALVE BODY
SN: 55001-(108656)
1шт.
2
0
SPOOL
SN: 55001-UP
1шт.
3
0
SPRING
SN: 55001-UP
1шт.
4
0
VALVE
SN: 55001-UP
1шт.
5
714-23-15650
PLUG
SN: 55001-UP
1шт.
6
0
SOLENOID
SN: (108468)-UP
1шт.
6
0
SOLENOID
SN: 55001-(108467)
1шт.
7
0
O-RING
SN: 55001-UP
1шт.
8
07002-22034
O-RING
SN: 55001-UP
1шт.
9
0
BALL
SN: 55001-UP
1шт.
10
07040-11007
PLUG
SN: (108657)-UP
2шт.
10
07042-80108
PLUG
SN: 55001-(108656)
2шт.
11
07002-61023
O-RING
SN: (108657)-UP
2шт.
12
01252-90650
BOLT
SN: (108657)-UP
4шт.
12
01252-60650
BOLT
SN: 55001-(108656)
4шт.
13
07000-72010
O-RING
SN: 55001-UP
4шт.
14
07235-10315
ELBOW
SN: 55001-UP
2шт.
15
07002-62034
O-RING
SN: 55001-UP
2шт.
16
195-22-75811
COVER
SN: 55001-UP
1шт.
17
01011-81270
BOLT
SN: 55001-UP
2шт.
18
01011-81270
BOLT
SN: 55001-(154177)
1шт.
19
01011-81240
BOLT
SN: 55001-UP
1шт.
20
01010-81250
BOLT
SN: 55001-UP
5шт.
21
01643-31232
WASHER
SN: 55001-UP
5шт.
22
01643-31232
WASHER
SN: (154178)-UP
3шт.
22
01643-31232
WASHER
SN: 55001-(154177)
4шт.
23
07000-72018
O-RING
SN: 55001-UP
1шт.
24
07000-75375
O-RING
SN: 55001-UP
1шт.
