/ / / / / / CARTRIGE ПАЛЕЦ (ПРАВ.)(№88-)
Запчасти Komatsu D375A-5D CARTRIGE ПАЛЕЦ (ПРАВ.)(№88-) ХОДОВАЯ
1
2
3
4
5
5
6
6
7
7
8
9
10
11
12
13
13
13
14
15
1
2
3
4
5
6
7
7
8
8
9
10
11
12
13
13
14
15
16
17
18
|$2
195-30-69400
PIN ASS'Y
SN: 17743-UP
12шт.
1
195-30-62420
RING
SN: 17743-UP
1шт.
2
195-30-62410
RING
SN: 17743-UP
1шт.
3
195-30-62430
RING
SN: 17743-UP
1шт.
4
195-30-62440
SHAFT
SN: 17743-UP
1шт.
5
195-30-62451
SPACER
SN: 17743-UP
2шт.
|$8
195-30-00950
FLOATING SEAL ASS'Y
SN: 17743-UP
2шт.
6
0
SEAL
SN: 17743-UP
4шт.
7
0
O-RING
SN: 17743-UP
4шт.
8
209-30-63150
PLUG
SN: 17743-UP
1шт.
9
195-30-66571
COVER
SN: 17743-UP
8шт.
10
01010-62455
BOLT
SN: 17743-UP
24шт.
11
01643-32460
WASHER
SN: 17743-UP
24шт.
12
07049-02430
PLUG
SN: 17743-UP
10шт.
13
07049-02430
PLUG
SN: 17743-UP
7шт.
14
01010-62455
BOLT
SN: 17743-UP
3шт.
15
01643-32460
WASHER
SN: 17743-UP
3шт.
|$6
195-32-04553
TRACK SHOE ASS'Y
|$7
195-32-04552
TRACK SHOE ASS'Y
|$8
195-32-04551
TRACK SHOE ASS'Y
|$9
195-32-04550
TRACK SHOE ASS'Y
1
195-32-63120
LINK
2
195-32-63130
LINK
|$19
195-32-08410
MASTER LINK K. L.H.
3
LINK,MASTER
4
LINK,MASTER
|$22
195-32-08420
MASTER LINK K. R.H.
5
LINK,MASTER
6
LINK,MASTER
7
195-32-62201
SEAL ASS'Y
8
195-32-61181
SPACER
9
195-32-61341
BUSHING
10
195-32-63153
PIN
10
195-32-63152
PIN
10
195-32-63151
PIN
11
195-32-41290
PLUG,LARGE
12
07059-20721
PLUG,SMALL
13
195-32-63230
RING
14
195-32-61371
SHOE
14
195-32-61370
SHOE
15
195-32-61210
BOLT, SHOE (Y0320-K01
16
195-32-61220
NUT, SHOE (Y0320-K01
17
195-32-61371
SHOE
17
195-32-61370
SHOE
18
195-32-61350
BOLT,MASTER LINK
