|$0
6136-72-1410
INJECTION PUMP ASS'Y
SN: 50001-UP
1шт.
|$1
6136-72-1450
INJECTION PUMP ASS'Y,(HIGH ALTITUDE SPEC.)
SN: 55043-UP
1шт.
|$2
6136-72-1460
INJECTION PUMP ASS'Y,(EUROPE SPEC.)
SN: 50001-UP
1шт.
|$$4
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451A TO 0481A.
-1шт.
|$$5
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$5
DK105410-6280
GOVERNOR ASS'Y
SN: 50001-UP
1шт.
|$6
DK105410-6380
GOVERNOR ASS'Y,(HIGH ALTITUDE SPEC.)
SN: 55043-UP
1шт.
|$$8
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451A AND 0452A.
-1шт.
1
DK154500-7520
COVER
SN: 50001-UP
1шт.
2
DK014110-3440
WASHER,SPRING
SN: 50001-UP
1шт.
3
DK026516-2040
GASKET
SN: 50001-UP
1шт.
4
DK154316-6600
ADAPTER
SN: 50001-UP
1шт.
5
DK154011-0100
NUT,LOCK
SN: 50001-UP
1шт.
6
DK154031-3000
SCREW
SN: 50001-UP
1шт.
7
DK029240-6010
NUT
SN: 50001-UP
1шт.
8
DK154036-0300
PLUG
SN: 50001-UP
1шт.
9
DK020106-5040
BOLT
SN: 50001-UP
2шт.
10
DK154010-0300
SCREW
SN: 50001-UP
1шт.
11
DK020106-3840
BOLT
SN: 50001-UP
4шт.
12
DK154063-5100
COVER
SN: 50001-UP
1шт.
13
DK029020-6210
BOLT
SN: 50001-UP
2шт.
14
DK020006-1640
BOLT
SN: 50001-UP
2шт.
15
DK154150-2700
SPRING
SN: 50001-UP
1шт.
16
DK154158-0820
CAPSULE,SPRING
SN: 50001-UP
1шт.
17
DK154011-1700
NUT
SN: 50001-UP
1шт.
18
DK026512-1540
GASKET
SN: 50001-UP
2шт.
19
DK154159-1200
NUT,CAP
SN: 50001-UP
1шт.
20
DK154200-3120
LEVER,SWIVEL
SN: 50001-UP
1шт.
21
DK154204-1900
BUSHING
SN: 50001-UP
2шт.
22
DK029631-8020
O-RING
SN: 50001-UP
2шт.
23
DK016010-1640
RING,SNAP
SN: 50001-UP
2шт.
24
DK139611-0000
SEAL,OIL
SN: 50001-UP
1шт.
25
DK139411-0000
SHIM, 0.40MM
SN: 50001-UP
1шт.
26
DK029311-1090
SHIM, 0.30MM
SN: 50001-UP
-2шт.
27
DK029141-7010
PLUG
SN: 50001-UP
1шт.
28
DK025803-1310
KEY, 13MM
SN: 50001-UP
1шт.
29
DK154206-2800
COLLAR
SN: 50001-UP
1шт.
30
DK154206-0200
WASHER, 1.0MM
SN: 50001-UP
-2шт.
31
DK154237-1100
PIN
SN: 50001-UP
1шт.
32
DK154341-7820
LEVER
SN: 50001-UP
1шт.
33
DK154350-7800
GASKET
SN: 50001-UP
1шт.
34
DK029635-2020
O-RING
SN: 50001-UP
1шт.
35
DK026506-1040
GASKET
SN: 50001-UP
2шт.
36
DK154035-1600
NUT,CAP
SN: 50001-UP
1шт.
37
DK029731-2040
BOLT,EYE
SN: 50001-UP
1шт.
38
DK029341-2140
GASKET
SN: 50001-UP
2шт.
|$0
6136-72-1410
INJECTION PUMP ASS'Y
SN: 50001-UP
1шт.
|$1
6136-72-1450
INJECTION PUMP ASS'Y,(HIGH ALTITUDE SPEC.)
SN: 55043-UP
1шт.
|$2
6136-72-1460
INJECTION PUMP ASS'Y,(EUROPE SPEC.)
SN: 50001-UP
1шт.
|$$4
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451A TO 0481A.
-1шт.
|$$5
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$5
DK105410-6280
GOVERNOR ASS'Y
SN: 50001-UP
1шт.
|$6
DK105410-6380
GOVERNOR ASS'Y,(HIGH ALTITUDE SPEC.)
SN: 55043-UP
1шт.
|$$8
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451A AND 0452A.
-1шт.
1
DK154500-7520
COVER
SN: 50001-UP
1шт.
2
DK014110-3440
WASHER,SPRING
SN: 50001-UP
1шт.
3
DK026516-2040
GASKET
SN: 50001-UP
1шт.
4
DK154316-6600
ADAPTER
SN: 50001-UP
1шт.
5
DK154011-0100
NUT,LOCK
SN: 50001-UP
1шт.
6
DK154031-3000
SCREW
SN: 50001-UP
1шт.
7
DK029240-6010
NUT
SN: 50001-UP
1шт.
8
DK154036-0300
PLUG
SN: 50001-UP
1шт.
9
DK020106-5040
BOLT
SN: 50001-UP
2шт.
10
DK154010-0300
SCREW
SN: 50001-UP
1шт.
11
DK020106-3840
BOLT
SN: 50001-UP
4шт.
12
DK154063-5100
COVER
SN: 50001-UP
1шт.
13
DK029020-6210
BOLT
SN: 50001-UP
2шт.
14
DK020006-1640
BOLT
SN: 50001-UP
2шт.
15
DK154150-2700
SPRING
SN: 50001-UP
1шт.
16
DK154158-0820
CAPSULE,SPRING
SN: 50001-UP
1шт.
17
DK154011-1700
NUT
SN: 50001-UP
1шт.
18
DK026512-1540
GASKET
SN: 50001-UP
2шт.
19
DK154159-1200
NUT,CAP
SN: 50001-UP
1шт.
20
DK154200-3120
LEVER,SWIVEL
SN: 50001-UP
1шт.
21
DK154204-1900
BUSHING
SN: 50001-UP
2шт.
22
DK029631-8020
O-RING
SN: 50001-UP
2шт.
23
DK016010-1640
RING,SNAP
SN: 50001-UP
2шт.
24
DK139611-0000
SEAL,OIL
SN: 50001-UP
1шт.
25
DK139411-0000
SHIM, 0.40MM
SN: 50001-UP
1шт.
26
DK029311-1090
SHIM, 0.30MM
SN: 50001-UP
-2шт.
27
DK029141-7010
PLUG
SN: 50001-UP
1шт.
28
DK025803-1310
KEY, 13MM
SN: 50001-UP
1шт.
29
DK154206-2800
COLLAR
SN: 50001-UP
1шт.
30
DK154206-0200
WASHER, 1.0MM
SN: 50001-UP
-2шт.
31
DK154237-1100
PIN
SN: 50001-UP
1шт.
32
DK154341-7820
LEVER
SN: 50001-UP
1шт.
33
DK154350-7800
GASKET
SN: 50001-UP
1шт.
34
DK029635-2020
O-RING
SN: 50001-UP
1шт.
35
DK026506-1040
GASKET
SN: 50001-UP
2шт.
36
DK154035-1600
NUT,CAP
SN: 50001-UP
1шт.
37
DK029731-2040
BOLT,EYE
SN: 50001-UP
1шт.
38
DK029341-2140
GASKET
SN: 50001-UP
2шт.
