|$0
144-871-0042
TRACK FRAME ASS'Y,L.H. (FOR ANGLE DOZER) (D60E)
SN: 46296-UP
1шт.
|$1
0
TRACK FRAME ASS'Y,L.H. (FOR ANGLE DOZER) (D60E)
SN: 45501-46295
1шт.
|$2
144-30-00062
TRACK FRAME ASS'Y,L.H. (FOR TILT DOZER) (D60E)
SN: 46296-UP
1шт.
|$3
0
TRACK FRAME ASS'Y,L.H. (FOR TILT DOZER) (D60E)
SN: 45852-46295
1шт.
|$4
0
TRACK FRAME ASS'Y,L.H. (FOR TILT DOZER) (D60E)
SN: 45001-45851
1шт.
|$5
144-871-0042
TRACK FRAME ASS'Y,L.H. (FOR ANGLE DOZER) (D65E)
SN: 47165-UP
1шт.
|$6
0
TRACK FRAME ASS'Y,L.H. (FOR ANGLE DOZER) (D65E)
SN: 45001-47164
1шт.
|$7
144-30-00062
TRACK FRAME ASS'Y,L.H. (FOR TILT DOZER) (D65E)
SN: 47165-UP
1шт.
|$8
0
TRACK FRAME ASS'Y,L.H. (FOR TILT DOZER) (D65E)
SN: 46983-47164
1шт.
|$9
0
TRACK FRAME ASS'Y,L.H. (FOR TILT DOZER) (D65E)
SN: 45001-46982
1шт.
|$10
144-871-0052
TRACK FRAME ASS'Y,R.H. (D60E)
SN: 46296-UP
1шт.
|$11
0
TRACK FRAME ASS'Y,R.H. (D60E)
SN: 45001-46295
1шт.
|$12
144-871-0052
TRACK FRAME ASS'Y,R.H. (D65E)
SN: 47165-UP
1шт.
|$13
0
TRACK FRAME ASS'Y,R.H. (D65E)
SN: 45001-47164
1шт.
|$14
144-871-5311
TRACK FRAME ASS'Y,L.H. (FOR ANGLE DOZER) (D60E)
SN: 46296-UP
1шт.
|$15
0
TRACK FRAME ASS'Y,L.H. (FOR ANGLE DOZER) (D60E)
SN: 45001-46295
1шт.
|$16
144-30-12312
TRACK FRAME ASS'Y,L.H. (FOR TILT DOZER) (D60E)
SN: 46296-UP
1шт.
|$17
0
TRACK FRAME ASS'Y,L.H. (FOR TILT DOZER) (D60E)
SN: 45852-46295
1шт.
|$18
0
TRACK FRAME ASS'Y,L.H. (FOR TILT DOZER) (D60E)
SN: 45001-45851
1шт.
|$19
144-871-5311
TRACK FRAME ASS'Y,L.H. (FOR ANGLE DOZER) (D65E)
SN: 47165-UP
1шт.
|$20
0
TRACK FRAME ASS'Y,L.H. (FOR ANGLE DOZER) (D65E)
SN: 45001-47164
1шт.
|$21
144-30-12312
TRACK FRAME ASS'Y,L.H. (FOR TILT DOZER) (D65E)
SN: 47165-UP
1шт.
|$22
0
TRACK FRAME ASS'Y,L.H. (FOR TILT DOZER) (D65E)
SN: 46983-47164
1шт.
|$23
0
TRACK FRAME ASS'Y,L.H. (FOR TILT DOZER) (D65E)
SN: 45001-46982
1шт.
|$24
144-871-5321
TRACK FRAME ASS'Y,R.H. (D60E)
SN: 46296-UP
1шт.
|$25
0
TRACK FRAME ASS'Y,R.H. (D60E)
SN: 45001-46295
1шт.
|$26
144-871-5321
TRACK FRAME ASS'Y,R.H. (D65E)
SN: 47165-UP
1шт.
|$27
0
TRACK FRAME ASS'Y,R.H. (D65E)
SN: 45001-47164
1шт.
2
144-30-51150
PLATE,(FOR D60E) (WELDED)
SN: 45108-UP
1шт.
2
0
PLATE,(FOR D60E) (WELDED)
SN: 45001-45107
1шт.
2
144-30-51150
PLATE,(FOR D65E) (WELDED)
SN: 46171-UP
1шт.
2
0
PLATE,(FOR D65E) (WELDED)
SN: 45001-46170
1шт.
3
141-30-31262
PLATE (WELDED)
SN: 45001-UP
1шт.
4
144-871-5361
GUARD,OUTER, FRONT, L.H. (WELDED)
SN: 45001-UP
1шт.
4
144-871-5351
GUARD,OUTER, FRONT, R.H. (WELDED)
SN: 45001-UP
1шт.
5
144-871-5351
GUARD,OUTER, REAR, L.H. (WELDED)
SN: 45001-UP
1шт.
5
144-871-5361
GUARD,OUTER, REAR, R.H. (WELDED)
SN: 45001-UP
1шт.
6
144-871-5351
GUARD,INNER, L.H. (WELDED)
SN: 45001-UP
1шт.
6
144-871-5361
GUARD,INNER, R.H. (WELDED)
SN: 45001-UP
1шт.
7
144-813-1390
SEAT (WELDED)
SN: 45001-UP
1шт.
|$40
145-30-31241
HEAD
SN: 45001-UP
1шт.
9
145-30-31250
BUSHING
SN: 45001-UP
1шт.
10
145-30-31320
SEAL,DUST
SN: 45001-UP
2шт.
11
141-30-31350
PIN
SN: 45001-UP
1шт.
12
07020-00000
FITTING,GREASE
SN: 45001-UP
1шт.
13
144-871-2311
GUARD,LH,OUTER
SN: 45001-UP
1шт.
13
144-871-2321
GUARD,RH,OUTER
SN: 45001-UP
1шт.
14
144-871-2331
GUARD,LH,INNER
SN: 45001-UP
1шт.
14
144-871-2341
GUARD,RH,INNER
SN: 45001-UP
1шт.
15
01010-51840
BOLT
SN: 45001-UP
28шт.
16
01643-31845
WASHER
SN: 45001-UP
28шт.
17
09205-18310
BOLT
SN: 45001-UP
12шт.
18
141-30-32181
COLLAR
SN: 45001-UP
12шт.
19
01580-11815
NUT
SN: 45001-UP
12шт.
20
01643-31845
WASHER
SN: 45001-UP
12шт.
21
130-30-12170
PLATE,OUTER, FRONT, L.H.
SN: 45001-UP
1шт.
21
130-30-12180
PLATE,OUTER, FRONT, R.H.
SN: 45001-UP
1шт.
22
130-30-12180
PLATE,OUTER, REAR, L.H.
SN: 45001-UP
1шт.
22
130-30-12170
PLATE,OUTER, REAR, R.H.
SN: 45001-UP
1шт.
23
130-30-12180
PLATE,INNER, L.H.
SN: 45001-UP
1шт.
23
130-30-12170
PLATE,INNER, R.H.
SN: 45001-UP
1шт.
24
01010-51430
BOLT
SN: 45001-UP
12шт.
25
01643-31445
WASHER
SN: 45001-UP
12шт.
26
144-30-12171
GUARD,L.H.
SN: 45001-UP
1шт.
26
144-30-12181
GUARD,R.H.
SN: 45001-UP
1шт.
27
01010-52050
BOLT
SN: 45001-UP
8шт.
28
01643-32060
WASHER
SN: 45001-UP
8шт.
