Запчасти Komatsu D61PX-15 ТРАНСМИССИЯ (CARRIRER) (/) F [СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА]

|1

134-15-71000

TRANSMISSION ASSEMBLY

SN: B40001-UP

1шт.

|$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO F2320-62A0.

-1шт.

1

14X-15-22340

CARRIER

SN: B40001-UP

1шт.

2

14X-15-22420

GEAR

SN: B40001-UP

4шт.

3

14X-15-29440

BEARING

SN: B40001-UP

4шт.

4

09233-12920

WASHER

SN: B40001-UP

8шт.

5

14X-15-22540

SHAFT

SN: B40001-UP

4шт.

6

04260-00635

BALL

SN: B40001-UP

4шт.

7

14X-15-22150

SPACER

SN: B40001-UP

1шт.

8

14X-15-22620

RING GEAR

SN: B40001-UP

1шт.

9

14X-15-29530

SNAP RING

SN: B40001-UP

1шт.

10

14X-15-29510

SNAP RING

SN: B40001-UP

1шт.

11

06000-06921

BEARING

SN: B40001-UP

1шт.

12

04070-00105

RING

SN: B40001-UP

1шт.

13

14X-15-22310

CARRIER

SN: B40001-UP

1шт.

14

14X-15-22410

GEAR

SN: B40001-UP

4шт.

15

14X-15-29440

BEARING

SN: B40001-UP

4шт.

16

09233-12920

WASHER

SN: B40001-UP

8шт.

17

14X-15-22540

SHAFT

SN: B40001-UP

4шт.

18

04260-00635

BALL

SN: B40001-UP

4шт.

19

14X-15-22190

SPACER

SN: B40001-UP

1шт.

20

14X-15-29610

BEARING

SN: B40001-UP

1шт.

21

04065-07525

RING

SN: B40001-UP

1шт.

22

14X-15-22610

RING GEAR

SN: B40001-UP

1шт.

23

14X-15-29520

SNAP RING

SN: B40001-UP

1шт.

24

06030-06918

BEARING

SN: B40001-UP

1шт.

25

04064-09030

RING

SN: B40001-UP

1шт.

26

04064-04518

RING

SN: B40001-UP

5шт.

27

14X-15-22210

GEAR

SN: B40001-UP

1шт.

28

14X-15-22220

GEAR

SN: B40001-UP

1шт.

29

14X-15-22250

GEAR

SN: B40001-UP

1шт.

30

14X-15-22240

GEAR

SN: B40001-UP

1шт.

31

04064-04819

RING

SN: B40001-UP

1шт.

32

14X-15-29540

RING

SN: B40001-UP

2шт.

33

04020-01228

PIN

SN: B40001-UP

2шт.
