1
144-43-81321
BRACKET,(FOR D60A)
SN: 50044-UP
1шт.
|1
144-43-81320
BRACKET,(FOR D60A)
SN: 50001-50043
1шт.
|1
144-43-81321
BRACKET,(FOR D65A)
SN: 50050-UP
1шт.
|1
144-43-81320
BRACKET,(FOR D65A)
SN: 50001-50049
1шт.
2
144-43-51181
FRAME,(FOR D60A)
SN: 50055-UP
1шт.
|2
0
FRAME,(FOR D60A)
SN: 50001-50054
1шт.
|2
144-43-51181
FRAME,(FOR D65A)
SN: 50075-UP
1шт.
|2
0
FRAME,(FOR D65A)
SN: 50001-50074
1шт.
2A
144-A62-8410
SEAL,(L=1000MM) (D60A)
SN: 50055-UP
1шт.
|2A
144-A62-8410
SEAL,(L=1000MM) (D65A)
SN: 50075-UP
1шт.
2B
144-Y11-3730
SEAL,(L=1000MM) (D60A)
SN: 50055-UP
1шт.
|2B
144-Y11-3730
SEAL,(L=1000MM) (D65A)
SN: 50075-UP
1шт.
2C
07049-01215
PLUG,(FOR D60A)
SN: 50055-UP
2шт.
|2C
07049-01215
PLUG,(FOR D65A)
SN: 50075-UP
2шт.
3
06120-03020
BEARING,NEEDLE
SN: 50001-UP
4шт.
4
06122-03004
SEAL,BEARING
SN: 50001-UP
4шт.
5
06120-02016
BEARING,NEEDLE
SN: 50001-UP
2шт.
6
06122-02004
SEAL,BEARING
SN: 50001-UP
2шт.
7
06120-05025
BEARING,NEEDLE
SN: 50001-UP
2шт.
8
06122-05004
SEAL,BEARING
SN: 50001-UP
4шт.
9
07020-00001
FITTING,GREASE
SN: 50001-UP
3шт.
10
07020-00000
FITTING,GREASE
SN: 50001-UP
1шт.
11
07049-04253
PLUG
SN: 50001-UP
1шт.
12
09415-03614
CAP
SN: 50001-UP
1шт.
13
01573-22310
SEAT
SN: 50001-UP
2шт.
14
01010-51270
BOLT
SN: 50001-UP
4шт.
15
01643-31232
WASHER
SN: 50001-UP
4шт.
16
01010-51235
BOLT
SN: 50001-UP
2шт.
17
01643-31232
WASHER
SN: 50001-UP
2шт.
18
120-43-34652
COVER
SN: 50001-UP
1шт.
19
01010-51225
BOLT
SN: 50001-UP
2шт.
20
01643-31232
WASHER
SN: 50001-UP
2шт.
21
144-54-81112
BOARD,DASH (D60A)
SN: 50055-UP
1шт.
|21
0
BOARD,DASH (D60A)
SN: 50044-50054
1шт.
|21
144-54-81110
BOARD,DASH (D60A)
SN: 50001-50043
1шт.
|21
144-54-81112
BOARD,DASH (D65A)
SN: 50075-UP
1шт.
|21
0
BOARD,DASH (D65A)
SN: 50050-50074
1шт.
|21
144-54-81110
BOARD,DASH (D65A)
SN: 50001-50049
1шт.
22
130-54-61270
GUIDE
SN: 50001-UP
2шт.
23
01010-51235
BOLT
SN: 50001-UP
10шт.
24
01643-31232
WASHER
SN: 50001-UP
10шт.
25
144-54-81131
COVER,(FOR D60A)
SN: 50044-UP
1шт.
|25
144-54-81130
COVER,(FOR D60A)
SN: 50001-50043
1шт.
|25
144-54-81131
COVER,(FOR D65A)
SN: 50050-UP
1шт.
|25
144-54-81130
COVER,(FOR D65A)
SN: 50001-50049
1шт.
26
23S-06-14990
SCREW
SN: 50001-UP
6шт.
27
362-06-21140
WASHER
SN: 50001-UP
6шт.
28
144-54-24120
COVER,(FOR TRIMMING DOZER)
SN: 50001-UP
1шт.
29
01010-51225
BOLT,(FOR TRIMMING DOZER)
SN: 50001-UP
7шт.
30
01602-21236
WASHER,SPRING (FOR TRIMMING DOZER)
SN: 50001-UP
7шт.
31
01643-31232
WASHER,(FOR TRIMMING DOZER)
SN: 50001-UP
7шт.
|32
144-A62-8481
COVER,(FOR D60A)
SN: 50055-UP
1шт.
|32
0
COVER,(FOR D60A)
SN: 50044-50054
1шт.
|32
144-A62-8481
COVER,(FOR D65A)
SN: 50075-UP
1шт.
|32
0
COVER,(FOR D65A)
SN: 50050-50075
1шт.
32
144-54-24120
COVER,(FOR D60A)
SN: 50044-UP
1шт.
|32
144-54-24120
COVER,(FOR D65A)
SN: 50050-UP
1шт.
33
144-Y11-3730
SEAL,(L=1000MM) (D60A)
SN: 50055-UP
3шт.
|33
0
SEAL,(L=1000MM) (D60A)
SN: 50044-50054
3шт.
|33
144-Y11-3730
SEAL,(L=1000MM) (D65A)
SN: 50075-UP
3шт.
|33
0
SEAL,(L=1000MM) (D65A)
SN: 50050-50074
3шт.
34
144-A62-8490
ABSORBER,(FOR D60A)
SN: 50044-UP
1шт.
|34
144-A62-8490
ABSORBER,(FOR D65A)
SN: 50050-UP
1шт.
35
144-A62-8510
ABSORBER,(FOR D60A)
SN: 50044-UP
1шт.
|35
144-A62-8510
ABSORBER,(FOR D65A)
SN: 50050-UP
1шт.
36
144-A62-8520
ABSORBER,(FOR D60A)
SN: 50044-UP
1шт.
|36
144-A62-8520
ABSORBER,(FOR D65A)
SN: 50050-UP
1шт.
37
01010-51225
BOLT,(FOR D60A)
SN: 50044-UP
7шт.
|37
01010-51225
BOLT,(FOR D65A)
SN: 50050-UP
7шт.
38
01602-21236
WASHER,(FOR D60A)
SN: 50044-UP
7шт.
|38
01602-21236
WASHER,(FOR D65A)
SN: 50050-UP
7шт.
39
01643-31232
WASHER,(FOR D60A)
SN: 50044-UP
7шт.
|39
01643-31232
WASHER,(FOR D65A)
SN: 50050-UP
7шт.
40
07049-01620
PLUG,(FOR STEEL CAB) (D60A)
SN: 50044-UP
6шт.
|40
07049-01620
PLUG,(FOR STEEL CAB) (D65A)
SN: 50050-UP
6шт.
