|1
6150-71-1323
INJECTION PUMP A.
SN: 36135-UP
1шт.
|1
0
INJECTION PUMP A.
SN: 26320-36134
1шт.
|$$3
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0455 TO 0483.
-1шт.
|$$4
THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
ND090100-6091
BODY ASS'Y
SN: 26320-UP
1шт.
|$$6
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0455 AND 0456.
-1шт.
1
ND090130-0171
HOLDER,DELIVERY VALVE
SN: 26320-UP
6шт.
2
ND090136-0870
SPRING,DELIVERY VALVE
SN: 26320-UP
6шт.
3
ND949140-2570
O-RING
SN: 26320-UP
6шт.
4
ND090140-1430
VALVE SUB ASS'Y,DELIVERY
SN: 26320-UP
6шт.
5
ND090150-3250
ELEMENT
SN: 26320-UP
6шт.
6
ND090160-0060
SLEEVE,CONTROL
SN: 26320-UP
6шт.
7
ND090212-0471
RACK,CONTROL
SN: 26320-UP
1шт.
8
ND090163-0131
SEAT,UPPER
SN: 26320-UP
6шт.
9
ND090164-0250
SPRING,PLUNGER
SN: 26320-UP
6шт.
10
ND090165-0150
SEAT,LOWER
SN: 26320-UP
6шт.
11
ND090170-0230
TAPPET ASS'Y
SN: 26320-UP
6шт.
12
ND090438-0390
SHIM¤ 1.75MM
SN: 26320-UP
-2шт.
|12
ND090438-0400
SHIM¤ 1.8MM
SN: 26320-UP
-2шт.
|12
ND090438-0410
SHIM¤ 1.85MM
SN: 26320-UP
-2шт.
|12
ND090438-0420
SHIM¤ 1.9MM
SN: 26320-UP
-2шт.
|12
ND090438-0430
SHIM¤ 1.95MM
SN: 26320-UP
-2шт.
|12
ND090438-0440
SHIM¤ 2.0MM
SN: 26320-UP
-2шт.
|12
ND090438-0450
SHIM¤ 2.05MM
SN: 26320-UP
-2шт.
|12
ND090438-0460
SHIM¤ 2.1MM
SN: 26320-UP
-2шт.
|12
ND090438-0470
SHIM¤ 2.15MM
SN: 26320-UP
-2шт.
|12
ND090438-0480
SHIM¤ 2.2MM
SN: 26320-UP
-2шт.
|12
ND090438-0490
SHIM¤ 2.25MM
SN: 26320-UP
-2шт.
|12
ND090438-0500
SHIM¤ 2.3MM
SN: 26320-UP
-2шт.
|12
ND090438-0510
SHIM¤ 2.35MM
SN: 26320-UP
-2шт.
|12
ND090438-0520
SHIM¤ 2.4MM
SN: 26320-UP
-2шт.
13
ND949013-5880
WASHER,PLATE
SN: 26320-UP
12шт.
14
ND090139-0020
O-RING
SN: 26320-UP
18шт.
15
ND949018-1730
WASHER,PLATE
SN: 26320-UP
6шт.
16
ND090215-0011
SCREW,GUIDE
SN: 26320-UP
1шт.
17
ND090114-0110
BUSHING,CONTROL RACK
SN: 26320-UP
2шт.
18
ND090367-0040
BUSHING,CONTROL RACK
SN: 26320-UP
1шт.
19
ND090018-0410
COVER,CONTROL RACK
SN: 26320-UP
1шт.
20
ND949018-1550
WASHER,PLATE
SN: 26320-UP
1шт.
