Запчасти Komatsu D87E-2 FIG. H-A ВОЗВРАТ. ФИЛЬТР. ГИДРАВЛИКА

|$0

1216 232 H92

BASE ASSEMBLY, FILTER

SN: P090001-UP

1шт.

1

NSS

BASE, FILTER

SN: P090001-UP

1шт.

2

1234 207 H92

KIT, SWITCH

SN: P090001-UP

1шт.

|$3

24 842 R1

BOLT, MOUNTING - 3/8NCx1-3/4

SN: P090001-UP

4шт.

|$4

25 534 R1

WASHER, FLAT - 3/8

SN: P090001-UP

8шт.

|$5

25 522 R1

NUT, HEX - 3/8NC

SN: P090001-UP

4шт.

3

1214 275 H4

ELEMENT, FILTER

SN: P090001-UP

1шт.

4

343 923 R1

RING, SEAL

SN: P090001-UP

2шт.

5

1222 004 H1

PLATE, COVER

SN: P090001-UP

2шт.

|$9

24 860 R1

BOLT, MOUNTING - 1/2NCx1

SN: P090001-UP

8шт.

|$10

25 536 R1

WASHER, FLAT - 1/2

SN: P090001-UP

8шт.
